09225VA-24Q-BL New fan 9225/24V

09225VA-24Q-BL New fan 9225/24V

$9.71

SKU: 728756163639 Brand:

Description

The 09225VA-24Q-BL is a premium-grade DC axial cooling fan designed for high-density power supply units and industrial control cabinets. Manufactured to strict Original Engineering standards, this 92mm component delivers exceptional thermal management through a high-velocity airflow profile. It features a built-in three-wire alarm system for real-time operational monitoring, ensuring maximum uptime in mission-critical infrastructure. With optimized Lead Time availability, this unit guarantees seamless Technical Compatibility with existing 24VDC cooling architectures.

Technical Specifications
Model Number: 09225VA-24Q-BL
Frame Dimensions: 92mm x 92mm x 25mm
Operating Voltage: 24V DC
Current Rating: 0.49 A
Power Consumption: 11.76 W
Bearing Type: Dual Ball Bearing
Termination: 3-Wire Lead (Power, Ground, Alarm)
Sensor Function: Locked Rotor Alarm
Airflow Capacity: High Volume (approx. 80 CFM)
Operating Temperature: -10°C to +70°C
Weight: 95 g
Housing Material: UL94V-0 Plastic
Impeller Material: UL94V-0 Plastic
Protection: Impedance and Polarity Protected

Model Decoding
09225: Frame size identifier (92mm x 25mm)
VA: DC Axial Fan Series
24: 24V DC Rated Voltage
Q: High-Speed / High-Airflow Motor Winding
B: Ball Bearing Configuration
L: 3-Wire with Locked Rotor Alarm Output

Application Scenario
This high-volume cooling fan is specifically engineered for heavy-duty power supply cooling, telecom base stations, and automated motor drive enclosures. In environments where thermal throttling can cause catastrophic system failure, the 09225VA-24Q-BL provides rapid heat dissipation. The integrated three-wire alarm sensor plays a critical role in these setups by instantly signaling control logic if the impeller locks due to debris or mechanical fault, allowing the system to safely shut down or switch to redundant cooling before thermal damage occurs.

09225VA-24Q-BL New fan 9225/24V

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
