2CC2312-1RA10-4CD6 Mdexx Centrifugal Fan for Siemens Motor

2CC2312-1RA10-4CD6 Mdexx Centrifugal Fan for Siemens Motor

$989.00

SKU: 62144347988 Brand: ,

Description

The Mdexx 2CC2312-1RA10-4CD6 is an industrial-grade centrifugal cooling fan engineered specifically for forced ventilation in high-capacity Siemens motors. Designed to maintain optimal thermal equilibrium, this unit ensures Technical Compatibility with SIMOTICS AC motors operating under continuous heavy-duty cycles.

Technical Specifications

Manufacturer: Mdexx
Model Number: 2CC2312-1RA10-4CD6
Equipment Type: Centrifugal Cooling Fan
Target Application: Siemens Motor Forced Ventilation
Operating Voltage: 400V / 690V ± 10% (3-Phase AC)
Frequency: 50 Hz / 60 Hz
Airflow Capacity: 1850 m³/h
Motor Speed: 2850 RPM
Protection Class: IP55
Insulation Class: F (155 °C)
Ambient Temperature Range: -20 °C to +50 °C
Impeller Material: Galvanized Steel
Housing Material: Sheet Steel with Corrosion-Resistant Coating
Weight: 32.5 kg
Noise Level: < 78 dB(A)

Application & Integration

This centrifugal fan is critical for variable speed drive (VSD) applications where the main motor operates at low speeds, requiring independent forced cooling to prevent thermal overload. The Original Engineering guarantees exact dimensional alignment with Siemens motor housings, minimizing installation downtime. Standard Lead Time applies for factory-direct replacements, ensuring rapid restoration of critical drive systems in steel mills, paper manufacturing, and heavy conveyor operations.

Key Attributes
Mounting: Free Standing
Voltage: 400v
Blade Material: Cast Iron
Electric Current Type: AC
Customized support: OEM
Warranty: 1 Year
After-sales Service Provided: Online support
Model number: 2CC2312-1RA10-4CD6
Place of origin: Germany
Brand name: Mdexx
Nominal voltage: 400V
Bearing Type: Ball Bearing
Power consumption: 3000W
Speed: 1650 (r/min)
Current: 1.7(A)
Frequency: 50~60Hz

Packaging and Delivery
Packaging Details: Carton package
Port of dispatch: Tianjin port
Selling Units: Single item

2CC2312-1RA10-4CD6 Mdexx Centrifugal Fan for Siemens Motor

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
