5E-380B Bi-Sonic fan
5E-380B Bi-Sonic fan
5E-380B Bi-Sonic fan
5E-380B Bi-Sonic fan

5E-380B Bi-Sonic fan

$22.14

SKU: 895520112410 Brand:

Description

Manufacturer: Bi-Sonic Technology Corp.
Model Number: 5E-380B
Origin: Taiwan
Product Type: AC Axial Cooling Fan
Dimensions: 120 x 120 x 38 mm
Rated Voltage: AC 380V
Frequency: 50/60 Hz
Input Power: 21/18 W
Rated Current: 0.06/0.05 A
Rated Speed: 2700/3100 RPM
Maximum Airflow: 95/115 CFM
Static Pressure: 0.33/0.38 Inch-H2O
Noise Level: 44/49 dB(A)
Bearing Type: Dual Precision Ball Bearing
Frame Material: Die-Cast Aluminum Alloy (ADC12)
Impeller Material: Glass Fiber Reinforced PBT (UL 94V-0)
Insulation Resistance: 100M Ohm min. at 500V DC
Dielectric Strength: 1500V AC for 1 minute
Operating Temperature: -20°C to +80°C
Storage Temperature: -40°C to +100°C
Service Life: 50,000 Hours at 25°C
Safety Certifications: UL, CUL, TUV, CE, RoHS
Weight: 530 g

Technical Compatibility and Application:
The Bi-Sonic 5E-380B is an industrial-grade thermal management solution specifically designed for high-voltage environments. Utilizing Original Engineering specifications from Taiwan, this axial fan is optimized for direct integration into 380V AC power systems, commonly found in industrial UPS chassis, server cabinets, and high-capacity switchgear. The high-temperature resistant construction and dual ball bearing architecture ensure reliable 24/7 operation in environments where thermal accumulation poses a risk to sensitive power electronics. By providing high-density airflow within a standard 120mm footprint, the 5E-380B solves critical cooling challenges in mission-critical infrastructure. Technical Compatibility with global industrial power standards makes it a primary choice for OEM cabinet manufacturers and maintenance engineers. Lead Time for this specialized component is optimized to support urgent lifecycle replacements and large-scale system deployments.

5E-380B Bi-Sonic fan

5E-380B Bi-Sonic fan

5E-380B Bi-Sonic fan

5E-380B Bi-Sonic fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
