Description
The A06B-6091-H145 is a high-performance Alpha i series Power Supply Module designed for large-scale CNC machining centers and high-torque robotics. It serves as the primary power conversion stage, rectifying AC input into a stable DC bus for multiple Servo and Spindle Amplifiers. The integrated power regeneration circuitry allows excess kinetic energy during motor deceleration to be returned to the grid, significantly improving overall system efficiency and reducing thermal load within the control cabinet.
Manufacturer: FANUC
Model Number: A06B-6091-H145
Product Series: Alpha i Power Supply Module (PSM-45i)
Country of Origin: Japan
Technical Specifications:
Input Voltage: 200-240V AC (+10%, -15%)
Input Phases: 3-Phase
Input Frequency: 50/60 Hz (±1 Hz)
Rated Output Capacity: 53 kW
Rated Output Current: 191 A
Control Power Supply: 24V DC (±10%)
Cooling Method: Forced Air Cooling (Internal Fan)
Regeneration Method: Power Regeneration to Line
Protection Rating: IP20 (IEC 60529)
Operating Temperature: 0°C to 55°C
Storage Temperature: -20°C to 60°C
Humidity: 95% RH or less (Non-condensing)
Weight: 18.0 kg
Dimensions (W x H x D): 150 mm x 380 mm x 307 mm
Industrial Application and Compatibility:
This module is critical for heavy-duty milling, turning, and grinding applications where high dynamic response and sustained power output are required. It is engineered for seamless integration with Fanuc 16i, 18i, and 21i Control Systems. The unit features built-in diagnostics for overcurrent, low voltage, and phase loss, ensuring maximum machine uptime in 24/7 manufacturing environments.
Original Engineering and Lifecycle Value:
As a genuine Fanuc Japan component, this unit adheres to strict Original Engineering standards, ensuring precise Technical Compatibility with existing Alpha i bus bars and communication cables. Utilizing authentic Fanuc hardware minimizes the risk of synchronization errors and protects the long-term integrity of the CNC system. Global Lead Time varies by region; contact technical sales for current availability and logistical support.
Key Attributes
Place of Origin: Japan
Model Number: A06B-6091-H145
Brand Name: FANUC
Product name: A06B-6091-H145
Condition: Original new
Warranty: 12 Months
Stock: Available
Shipping terms: All terms are accepted
Payment terms: All terms are accepted
Lead Time: 1-2 Days
Delivery Time: 3-5 Days
Package: Carton packing
MOQ: 1 Piece
Packaging and Delivery
Selling Units: Single item
