Manufacturer: Asia Vital Components (AVC)
Model Number: DYTB0838B8U
Frame Dimensions: 80 mm x 80 mm x 38 mm
Bearing Type: Precision Dual Ball Bearing
Rated Voltage: 48V DC
Operating Voltage Range: 28.0V to 56.0V DC
Rated Current: 0.63A
Input Power: 30.24W
Rotational Speed: 7500 RPM
Maximum Airflow: 105.6 CFM
Static Pressure: 31.2 mm-H2O
Noise Level: 61.5 dBA
Material Frame: Glass Fiber Reinforced PBT (UL94V-0)
Material Impeller: Glass Fiber Reinforced PBT (UL94V-0)
Termination: Multi-conductor Lead Wires
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +75°C
Life Expectancy: 70,000 Hours at 40°C
Safety Certifications: UL, TUV, CE, RoHS Compliant
Weight: 190g
Industrial Application Profile:
The AVC DYTB0838B8U is a high-velocity thermal management solution engineered for mission-critical B2B infrastructure. Featuring a 38mm deep-frame design, this unit generates the high static pressure required to drive airflow through high-density heat sinks and obstructed industrial enclosures. It is specifically optimized for 48V DC telecommunications racks, server power supply units (PSUs), and automated industrial control cabinets.
Original Engineering: This component adheres to genuine AVC Taiwan manufacturing standards, ensuring strict tolerance matching and rotational balance.
Technical Compatibility: Direct replacement for 8038 series high-amperage fans in enterprise-grade networking hardware.
Lead Time: Available for immediate integration into maintenance cycles to minimize system downtime.
Reviews
There are no reviews yet.
Only logged in customers who have purchased this product may leave a review.
Fans Maintenance and upkeep
1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;
2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.
3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;
4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
