$208.00

SKU: 1601572361861 Brand:

Description

The ebm-papst A4D350-AN08-01 is a high-performance AC axial fan engineered for demanding industrial cooling and ventilation applications. Utilizing Original Engineering principles, this unit delivers exceptional aerodynamic efficiency and acoustic performance, making it a critical component for thermal management in continuous-duty environments.

Technical Specifications:
Manufacturer: ebm-papst
Model Number: A4D350-AN08-01
Fan Type: AC Axial Fan
Motor Design: 3-Phase AC Motor (4-Pole)
Nominal Voltage: 230V / 400V (Delta/Star)
Frequency: 50 Hz
Power Consumption: 170 W
Nominal Speed: 1370 RPM
Maximum Air Volume: 2105 m³/h
Impeller Diameter: Ø 350 mm
Airflow Direction: A (Air over motor)
Protection Rating: IP44
Insulation Class: F
Bearing System: Maintenance-free Ball Bearings
Blade Material: Sheet steel, painted black
Weight: 4.6 kg
Operating Temperature Range: -25°C to +65°C

Application & Lifecycle Value:
This specific axial fan is optimized for integration into air conditioning cabinets, electrical control enclosures, and telecom base stations. The robust 2105 m³/h airflow capacity ensures rapid heat dissipation, preventing thermal throttling in sensitive electronic components. Its sheet steel construction and IP44 rating provide resilience against dust and moisture ingress in harsh industrial facilities.

Procurement & Integration:
We guarantee exact Technical Compatibility with existing ebm-papst installations, ensuring seamless drop-in replacement and minimal system downtime. Contact our technical sales team to confirm current inventory levels and secure an expedited Lead Time for your facility’s maintenance schedule.

Voltage: 230 V
Material: Plastic
Speed: 1370RPM
Mounting type: Free Standing
Type: Ac axial fan
Warranty: 1 Year
Blade Diameter: 350MM
Power Source: Electric
Blade material: Plastic
Bearing type: Ball Bearing
After-sales service provided: Online support
Place of origin: Germany
Brand name: Ebmpapst
Model number: A4D350-AN08-01
Motor: M4D074-DF
Phase: 3~
Weight: 3.2 kg
Motor size: 74mm
Material of blades: Press-fitted sheet steel blank, sprayed with PP plastic
Number of blades: 5
Insulation class: F
Environmental protection class (H): H1
Direction of rotation: Counter-clockwise, seen on rotor
Selling Units: Single item
Single package size: 45X45X26 cm
Single gross weight: 4.500 kg

ebmpapst A4D350-AN08-01 Industrial Fan 230V 1370RPM 170W 2105m³/h Air Conditioning Fan Electric AC Axial Fan

ebmpapst A4D350-AN08-01 Industrial Fan 230V 1370RPM 170W 2105m³/h Air Conditioning Fan Electric AC Axial Fan

ebmpapst A4D350-AN08-01 Industrial Fan 230V 1370RPM 170W 2105m³/h Air Conditioning Fan Electric AC Axial Fan

ebmpapst A4D350-AN08-01 Industrial Fan 230V 1370RPM 170W 2105m³/h Air Conditioning Fan Electric AC Axial Fan

ebmpapst A4D350-AN08-01 Industrial Fan 230V 1370RPM 170W 2105m³/h Air Conditioning Fan Electric AC Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
