Ebmpapst S4E300-EE20-06 230V AC Axial Fan

Ebmpapst S4E300-EE20-06 230V AC Axial Fan

$79.65

SKU: 1601164149362 Brand:

Description

The ebmpapst S4E300-EE20-06 is a high-performance AC axial flow fan engineered for demanding thermal management and industrial exhaust applications. Designed with a robust external rotor motor, this unit delivers exceptional air-moving capabilities while maintaining the structural resilience necessary for continuous heavy-duty operation.

Technical Specifications:
Brand: ebmpapst
Model Number: S4E300-EE20-06
Fan Type: AC Axial Flow Fan
Nominal Voltage: 230V AC
Frequency: 50 / 60 Hz
Maximum Air Volume: 2070 m³/h
Impeller Diameter: Ø 300 mm
Motor Configuration: 4-pole single-phase motor
Speed: High RPM configuration (approx. 1350 to 1420 RPM)
Blade Material: Sheet steel, coated in black
Protection Rating: IP44
Insulation Class: B
Operating Temperature: -25 °C to +60 °C
Motor Protection: Thermal overload protector (TOP) wired internally
Bearings: Maintenance-free ball bearings
Weight: 3.5 kg

Application and System Integration:
Engineered specifically to solve complex thermal regulation challenges, the S4E300-EE20-06 is highly suited for commercial refrigeration racks, high-capacity compressor arrays, and condenser units. By providing an aggressive 2070 m³/h airflow, it actively prevents overheating in tightly packaged fluid compression systems, ensuring stable temperatures across extended operation cycles. Backed by ebm-papst’s standard of Original Engineering, this component offers exact Technical Compatibility for drop-in replacement in legacy systems, guaranteeing restored efficiency and prolonged equipment lifecycle. Please consult our industrial distribution team regarding current inventory status and projected Lead Time for domestic and international deployment.

Key Attributes
Voltage: 230V
Electric current type: AC
Mounting type: Free Standing
Warranty: 1 Year
Blade material: Plastic
Customized support: OEM, ODM
After-sales service provided: Online support
Place of origin: Germany
Brand name: Ebmpapst
Model number: S4E300-EE20-06
Nominal voltage: 230V
Bearing Type: Ball Bearing
Power input: 70/90W
Air flow: 2070 m3/h
Speed: 1500RPM
Blade Diameter: 300mm

Packaging and Delivery
Selling Units: Single item
Single package size: 37X37X35 cm
Single gross weight: 6.300 kg

Ebmpapst S4E300-EE20-06 230V AC Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
