$1,099.00

SKU: 1600832915506 Brand:

Description

The ebm-papst W3G710-GO81-01 is a high-efficiency EC axial fan engineered for demanding thermal management and industrial ventilation systems. Utilizing advanced electronically commutated (EC) motor technology, this unit delivers optimized aerodynamic performance with precise speed control. The integrated wall ring facilitates streamlined installation and exact airflow direction in high-capacity cooling environments.

Technical Specifications:
Manufacturer: ebm-papst
Model Number: W3G710-GO81-01
Fan Design: Axial Fan with Wall Ring
Motor Technology: 3-Phase EC (Electronically Commutated)
Nominal Voltage: 400 VAC
Power Consumption: 930 W
Nominal Speed: 900 RPM
Current Draw: 1.5 A
Impeller Diameter: Ø 710 mm
Degree of Protection: IP54
Bearing System: High-precision Ball Bearing
Insulation Class: F
Operating Temperature: -25 °C to +60 °C
Weight: Approx. 24.5 kg
Motor Protection: Integrated thermal overload and locked-rotor protection

Industrial Application:
This axial fan is specifically designed for integration into large-scale air conditioning units, commercial condenser systems, and industrial heat exchangers. Its Ø 710 mm sweep and 900 RPM operational speed provide the high volumetric flow rates (m³/h) required to dissipate heavy heat loads in data center chiller plants and manufacturing facilities. The IP54 rating ensures resilient operation against dust and water ingress in exposed outdoor condenser arrays.

Procurement & Lifecycle Value:
Ensuring strict Technical Compatibility with existing HVAC infrastructure, this Original Engineering component guarantees exact fitment and baseline performance restoration. Our optimized logistics network minimizes Lead Time for critical replacement parts, reducing system downtime and maintaining continuous thermal regulation in mission-critical operations.

Key Attributes
Mounting: Free Standing
Voltage: 400V
Blade Material: Aluminium sheet insert, sprayed with PP plastic
Customized support: OEM, ODM
Warranty: 1 Year
After-sales Service Provided: Online support
Model number: W3G710-GO81-01
Place of origin: Germany
Brand name: Ebmpapst
Nominal voltage: 400V
Power consumption: 930W
Speed: 900RPM
Current: 1.5A
Frequency: 50~60Hz
Number of blades: 5
Insulation class: B
IP rating: IP54
Motor bearing: Ball bearing
Weight: 27.2Kg

Packaging and Delivery
Selling Units: Single item
Single package size: 100X100X45 cm
Single gross weight: 68.000 kg

ebmpapst W3G710-GO81-01 400V 930W 900RPM 1.5A 710mm IP54 Air Conditioner Unit Fan Condenser Axial Fan

ebmpapst W3G710-GO81-01 400V 930W 900RPM 1.5A 710mm IP54 Air Conditioner Unit Fan Condenser Axial Fan

ebmpapst W3G710-GO81-01 400V 930W 900RPM 1.5A 710mm IP54 Air Conditioner Unit Fan Condenser Axial Fan

ebmpapst W3G710-GO81-01 400V 930W 900RPM 1.5A 710mm IP54 Air Conditioner Unit Fan Condenser Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
