Elcometer 215 G215-2T High Temperature Thermal Barrier Oven Data Logger Kit Customized

Description

The Elcometer 215 G215-2T High Temperature Thermal Barrier Oven Data Logger Kit is a precision-engineered thermal profiling system designed for comprehensive temperature monitoring during industrial curing processes. This professional-grade kit enables powder coating applicators, industrial paint shops, and quality control laboratories to verify and optimize oven performance, ensuring complete cure profiles in compliance with international standards.

Technical Specifications
Manufacturer: Elcometer
Model Number: G215-2T
Logger Type: Elcometer 215 Oven Profiler
Number of Channels: 6 Channels (Type K Thermocouple)
Measurement Range: -200°C to 1300°C
Accuracy: ±0.5°C (±0.9°F)
Resolution: 0.1°C (0.1°F)
Memory Capacity: 260,000 readings across up to 8 runs
Sampling Interval: Adjustable from 0.1 seconds to 60 minutes
Operating Temperature of Logger: 0°C to 60°C (without thermal barrier)
Thermal Barrier Material: High-grade stainless steel outer casing with advanced microporous insulation and internal heat sink
Thermal Barrier Performance at 100°C: 300 minutes
Thermal Barrier Performance at 150°C: 210 minutes
Thermal Barrier Performance at 200°C: 150 minutes
Thermal Barrier Performance at 250°C: 120 minutes
Thermal Barrier Performance at 300°C: 100 minutes
Power Supply: 3 x AA alkaline batteries
Battery Life: Up to 200 hours of continuous logging
Data Interface: USB connection to PC
Software Compatibility: ElcoMaster Software
Thermal Barrier Dimensions: 265mm x 215mm x 135mm
Weight: 4.2 kg (including thermal barrier and heat sink)
Certifications: CE, RoHS, traceable to national standards

System Architecture and Technical Compatibility
The G215-2T architecture is built around a high-precision 6-channel data logging module housed within a robust, double-walled stainless steel thermal barrier. This barrier utilizes advanced phase-change heat sink technology to absorb thermal energy, protecting the internal electronics from extreme heat. The system features seamless Technical Compatibility with a wide array of Type K thermocouple probes, including magnetic, clamp, and exposed junction configurations, allowing for simultaneous measurement of both air and surface temperatures. The integrated USB interface ensures rapid data transfer to ElcoMaster software for automated cure analysis, calculation of the Cure Index, and generation of professional PDF reports.

Industrial Application Scenario
In high-temperature automotive OEM paint curing lines and heavy industrial PTFE coating applications, maintaining strict adherence to the manufacturer’s cure window is critical. Under-curing leads to poor adhesion and mechanical failure, while over-curing causes discoloration and brittleness. The Elcometer 215 G215-2T solves this by traveling through the conveyorized oven alongside the component. As the assembly passes through the multi-zone burner system, the 6-channel logger continuously records real-time temperature profiles at critical structural points. The high-temperature thermal barrier ensures the logger remains below its 60°C operational limit even during a 2-hour cure cycle at 250°C, providing the precise thermal data required to validate process parameters and prevent costly product recalls.

Commercial and Lifecycle Value
As an Original Engineering solution, the Elcometer G215-2T guarantees long-term calibration stability, rugged durability in harsh industrial environments, and complete backward compatibility with existing Elcometer probe systems. Standard Lead Time for this specialized kit is optimized to support rapid deployment and minimize production downtime. Customized OEM and ODM configurations are supported to meet specific industrial requirements, including specialized probe lengths, custom thermal barrier dimensions, and dedicated software integration protocols.

Key Attributes
Type: Oven Data Logger
Place of origin: United Kingdom
Model number: G215----2T
Brand name: Elcometer
Customized support: OEM, ODM
Infrared resolution: Other
Material: High temperature resistant material
Warranty: 1 years
Gauge Measurement Range: -200°C to 1300°C (-328°F to 2372°F)
Gauge Operating Temperature: -30°C to 65°C (-22°F to 149°F)
Accuracy: ±0.5°C
Measuring Intervals: Adjustable from 8 per second to 1 per hour
Dimensions: 245 x 245 x 115mm
Weight: 6kg

Packaging and Delivery
Selling Units: Single item
Single package size: 45X40X21 cm
Single gross weight: 8.000 kg
