FLIR TG267 Industrial High Temperature Spot Thermal Camera Electronic Power Source Complementing FLIR TG297 and TG165-X Series

Description

The FLIR TG267 is a ruggedized radiometric diagnostic tool engineered for baseline thermography, preventive electrical infrastructure monitoring, and mechanical system evaluation. Manufactured to rigorous Original Engineering standards, the unit integrates a 160 × 120 Lepton infrared sensor with FLIR proprietary Multi-Spectral Dynamic Imaging (MSX) edge-enhancement technology. This device combines non-contact thermal measurement up to 380 °C with direct contact Type-K thermometry, bridging the capability gap between single-spot infrared thermometers and high-end thermal imaging cameras.

Technical Specifications:
Manufacturer: Teledyne FLIR
Model Number: TG267
IR Resolution: 160 × 120 pixels (19,200 measurement points)
Thermal Sensitivity (NETD): < 70 mK (0.07 °C)
Object Temperature Range: -25 °C to 380 °C (-13 °F to 716 °F)
Measurement Accuracy: ±1.5 °C for 50 °C to 100 °C; up to ±2.5 °C for -25 °C to 50 °C and 100 °C to 380 °C
Field of View (FOV): 57° × 44°
Spatial Resolution (IFOV): 6.0 mrad
Spectral Range: 7.5 to 14 µm
Detector Pitch: 12 µm
Focus Mechanism: Fixed focus (minimum focus distance 0.3 m)
Visual Camera Resolution: 2 Megapixel (1600 × 1200 pixels)
Display Type: 2.4-inch portrait color LCD (320 × 240 pixels)
Image Modes: MSX (Thermal with visual edge embossing), Visual with thermal reading
Target Alignment: Class 1 multipoint bullseye laser indicator
Contact Thermometry Port: Type-K thermocouple interface (-30 °C to 300 °C included probe range)
Internal Data Storage: 4 GB eMMC (stores up to 50,000 radiometric JPEG files)
Connectivity: Bluetooth Low Energy (BLE) for wireless transfer to mobile devices
Data / Charging Port: USB Type-C (USB 2.0 protocol)
Power Source: Rechargeable 3.7 V internal Lithium-Ion battery
Operating Time: Minimum 5 hours continuous scanning
Recharge Cycle Time: 4 hours to 90% via USB-C
Enclosure Ingress Protection: IP54 (IEC 60529 standard for dust and splash resistance)
Impact Resistance: 2.0 m (6.6 ft) drop-tested housing
Operating Temperature: -10 °C to 45 °C (14 °F to 113 °F)
Storage Temperature: -30 °C to 55 °C (-22 °F to 131 °F)
Dimensions: 210 × 64 × 81 mm
Weight: 0.394 kg
Compliance & Certifications: CE, UKCA, RCM, FCC Class B, RoHS

Industrial Application & Problem Resolution:
The FLIR TG267 is engineered for plant maintenance technicians, facility electrical contractors, and reliability engineers troubleshooting electrical control panels, switchgear connections, motor bearing housings, and commercial HVAC ducting. In environments subject to heavy mechanical vibration and dust, undetected loose terminations or bearing friction create localized thermal hotspots prior to equipment shutdown. The multipoint bullseye laser defines the exact measurement surface, while MSX technology embosses legible text from breaker labels and terminal markers directly onto radiometric images. Contact Type-K capability allows immediate dual-verification between radiative thermal signatures and physical contact temperature.

Technical Compatibility & Procurement:
Technical Compatibility: Seamlessly integrates with FLIR Tools Mobile and FLIR Thermal Studio software for automated radiometric data export, thermographic batch processing, and audit reporting. Functions as an intermediate diagnostic unit interoperable with inspection workflows utilizing the FLIR TG165-X entry model and FLIR TG297 ultra-high-temperature systems.
Original Engineering: Authentic factory-calibrated unit manufactured under standard OEM calibration tolerances.
Lead Time: In-stock standard dispatch within 24 to 48 hours. Factory order lead time is 1 to 2 weeks depending on regional logistics and volume requirements.

Key Attributes
Type: Thermal Camera
Accuracy: 1%
Place of origin: China
Customized support: Software Reengineering
Power: -13 to 716°F (-25 to 380°C)
Protection Class: IP65
Voltage: 220 V
Brand name: FLIR
Warranty: 1 years
IR Resolution: 160 x 120 pixels
Digital Image Enhancement: Yes
Thermal Sensitivity/NETD: <70 mK
Image Frequency: 8.7 Hz
Display Resolution: 320 x 240 pixels
Object Temperature Range: -13 to 1886°F (-25 to 1030°C)
Measurement Accuracy: ± 1.5%
Power: Electronic

Packaging and Delivery
Selling Units: Single item
Single package size: 32X17X12 cm
Single gross weight: 1.500 kg
