Description
The Fluke 1777 is a high-performance Three-Phase Power Quality Analyzer designed for advanced power quality studies and high-speed electrical event capture. This instrument integrates the functionality of a power quality logger with the high-resolution capabilities of a transient recorder, enabling the identification of complex power issues in industrial and utility environments.
Technical Specifications:
Model: Fluke 1777
Measurement Type: Three-Phase + Neutral
Voltage Measurement Range: Up to 1000 V AC/DC
Transient Capture Sampling Rate: 20 MHz
Transient Voltage Peak: Up to 8 kV
Frequency Range: 42.5 Hz to 69 Hz
Accuracy Class: IEC 61000-4-30 Class A Edition 3
Display: 7-inch capacitive touch screen
Connectivity: USB, Ethernet, Wi-Fi, Bluetooth
Storage: Internal 32 GB
Power Supply: 100 V to 240 V AC / 50/60 Hz
Operating Temperature: -10 °C to +50 °C
Storage Temperature: -20 °C to +60 °C
Relative Humidity: < 90 % non-condensing
IP Rating: IP50 (IEC 60529)
Safety Rating: CAT IV 600 V / CAT III 1000 V
Dimensions: 28.0 cm x 19.0 cm x 6.2 cm
Weight: 2.1 kg
Advanced Features and Logic:
The Fluke 1777 utilizes a streamlined user interface that automatically scales measurements and provides guided setups to eliminate connection errors. The high-speed transient capture logic allows for the detection of sub-microsecond events that can damage sensitive electronics or cause system-wide resets. The device supports ‘Energy Study’ and ‘Power Quality Health’ modes, providing automated analysis against EN 50160 and IEEE 519 standards.
Industrial Application:
This analyzer is critical for facilities experiencing intermittent equipment failure or unexplained downtime. By capturing high-amplitude voltage transients and harmonic distortion, it allows maintenance engineers to pinpoint whether the source of the disturbance is internal (VFD switching, heavy motor starts) or external (grid switching, lightning). It ensures Technical Compatibility with modern renewable energy systems and complex data center power distributions.
Logistics and Compliance:
Original Engineering: Fluke Corporation
Lead Time: Standard stock item; subject to regional availability
Certifications: CE, CSA, RCM, IEC 61010-1
Calibration: NIST traceable calibration certificate included
Key Attributes
Accuracy Class: Class 1
Measuring Energy Range: ±8kV
Phase: Three Phase
Place of Origin: Romania
Model Number: 1777
Brand Name: Fluke
Dimensions: 28 x 19 x 6.2 cm
Display Type: Digital Only
Operating Temperature: -25℃ to +55℃
Output Voltage: 230/400V
Measurement Category: 1000 V CAT III/600 V CAT IV
Maximum Input Voltage: 1000 V rms/1000 V DC (1700 Vpk)
Resolution: 24-bit synchronous sampling
Sampling Frequency: 80 kS/second at 50/60 Hz
Measurement Range: ±8 kV
Sampling Rate: 1 MS/second 20 MS/second
Bandwidth: DC to 1 MHz
Packaging and Delivery
Selling Units: Single item
Single package size: 52X40X35 cm
Single gross weight: 8.000 kg
