Description
The Fluke 87V MAX True RMS Industrial Multimeter represents the pinnacle of diagnostic reliability for extreme industrial environments. Engineered to withstand a 4-meter drop and featuring an IP67 waterproof and dustproof rating, this instrument delivers precise electrical measurements in the most demanding conditions.
Technical Specifications:
Brand: Fluke
Model: 87V MAX (87VC)
Measurement Type: True RMS AC/DC
DC Voltage Range: 0.1 mV to 1000 V
DC Voltage Accuracy: ±(0.05% + 1)
AC Voltage Range: 0.1 mV to 1000 V
AC Voltage Accuracy: ±(0.7% + 2)
DC/AC Current Range: 0.1 µA to 10 A (20 A for 30 seconds maximum)
Resistance Range: 0.1 Ω to 50 MΩ
Capacitance Range: 0.01 nF to 9999 µF
Frequency Range: 0.5 Hz to 200 kHz
Temperature Measurement Range: -200 °C to 1090 °C
Low-Pass Filter: Integrated for accurate voltage and frequency measurements on VFDs
Safety Rating: EN 61010-1, CAT IV 600 V, CAT III 1000 V
Ingress Protection: IP67 (Dustproof and Waterproof)
Drop Resistance: 4 meters (13 feet)
Power Supply: 3 x AA Alkaline batteries
Battery Life: 800 hours typical (without backlight)
Operating Temperature: -15 °C to +55 °C (to -40 °C for 20 minutes)
Weight: 698 g (with holster)
Industrial Application:
The Fluke 87V MAX is specifically designed for troubleshooting complex motor drives, automated plant machinery, and power distribution systems. Its integrated low-pass filter allows technicians to accurately isolate and diagnose variable frequency drive (VFD) outputs, resolving erratic motor behavior in heavy manufacturing facilities. The robust IP67 casing ensures uninterrupted operation in high-particulate environments such as cement plants, mining operations, and offshore platforms.
Procurement Information:
Original Engineering: 100% authentic Fluke manufacturing ensuring certified calibration and safety compliance.
Technical Compatibility: Seamlessly integrates with standard Fluke test leads, current clamps, and K-type thermocouple probes.
Lead Time: Brand new in stock for immediate global dispatch to minimize facility downtime.
Key Attributes
Measuring Current Range: 10 A
Measuring Voltage Range: 1000 V
Parameters Measured: Temperature (K), DC Current, AC Voltage
Place of Origin: China
Model Number: 87VC
Brand Name: Fluke
Dimensions: 7.9 x 3.8 x 2" (201 x 98 x 52 mm)
Feature: Waterproof
Low Battery Indicator: Yes
Material: PVC
Max. AC Current: 10A
Max. AC Voltage: 1000 V
Max. DC Current: 10A
Max. DC Voltage: 1000 V
Measuring Capacitance Range: 9,999μF
Measuring Inductance Range: ,
Measuring Resistance Range: 50 MΩ
Operating Temperature: -20 to + 55°C
Voltage DC/AC: 1000 V
Current DC/AC: 10A
Resistance Maximum resistance: 50 MΩ
Frequency Maximum frequency: 200 kHz
Temperature Measurement: -328.0 to 1994.0°F (-200.0 to 1090°C)
Agency Approvals: CE, CSA, RCM
Display Digital: 6000 counts updates 4/seconds
Display Analog: 32 segments, updates 40/seconds
Packaging and Delivery
Selling Units: Single item
Single package size: 30X18X15 cm
Single gross weight: 1.800 kg
