FULLTECH UF-18JC23BTH 230V AC 75W 18cm 180x180x90mm 0.42A 2850RPM 390CFM Square UPS Power Supply Axial Fan

FULLTECH UF-18JC23BTH 230V AC 75W 18cm 180x180x90mm 0.42A 2850RPM 390CFM Square UPS Power Supply Axial Fan

$63.60

SKU: 62304398521 Brand:

Description

The FULLTECH UF-18JC23BTH is an industrial-grade AC axial flow cooling fan engineered for high-density thermal management in mission-critical infrastructure. Designed to meet strict Original Engineering specifications, this unit provides exceptional reliability for continuous-duty applications.

Technical Specifications:
Manufacturer: FULLTECH
Model Number: UF-18JC23BTH
Fan Type: AC Axial Flow Cooling Fan
Rated Voltage: 230V AC
Operating Frequency: 50/60 Hz
Power Consumption: 75 W
Rated Current: 0.42 A
Rotational Speed: 2850 RPM
Maximum Airflow: 390 CFM (11.04 m³/min)
Dimensions: 180 x 180 x 90 mm
Mounting Holes: 4 x Ø 4.5 mm
Bearing System: Dual Ball Bearing (B)
Connection Method: Terminal (T)
Motor Type: Capacitor-Run Induction Motor
Frame Material: Die-cast Aluminum Alloy
Impeller Material: High-grade Thermoplastic PBT (UL94V-0)
Operating Temperature: -20°C to +70°C
Weight: 1.8 kg
Dielectric Strength: 1500V AC for 1 minute
Insulation Resistance: >100M Ohm at 500V DC
Noise Level: ± 62 dB(A)

Industrial Application:
This high-performance axial fan is specifically engineered for high-capacity Uninterruptible Power Supply (UPS) systems, telecommunications cabinets, and heavy-duty industrial control panels. By delivering a massive 390 CFM of directed airflow, the UF-18JC23BTH rapidly dissipates heat generated by power inverters, transformers, and variable frequency drives. Its robust die-cast aluminum frame and dual ball bearing architecture ensure long-term Technical Compatibility and vibration resistance in harsh environments.

Procurement and Lifecycle Value:
Sourcing this component ensures exact alignment with OEM thermal requirements. We provide accurate Lead Time estimates to minimize downtime during critical maintenance cycles, ensuring your power infrastructure remains operational and thermally stable.

Key Attributes
Mounting: Free Standing
Voltage: 230V
Blade material: Metal
After-sales Service Provided: Online support
Warranty: 1 Year
Customized support: OEM
Place of origin: Taiwan, China
Power: 75W
Brand name: FULLTECH
Product name: UF18JC23-BTH
Voltage: 230V
Specifications: 180*180*90MM
Port: Tianjin port
Power: 75W
Current: 0.42A
Speed: 2850 rpm
Air flow: 390cfm

Packaging and Delivery
Packaging Details: 20*19*10 for Carton
Port of dispatch: Tianjin port
Selling Units: Single item

FULLTECH UF-18JC23BTH 230V AC 75W 18cm 180x180x90mm 0.42A 2850RPM 390CFM Square UPS Power Supply Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
