Description
The Mitsubishi HG-KN23J-S100 is a low-inertia, small-capacity AC servo motor engineered for high-precision dynamic motion control within the MELSERVO-JE and MELSERVO-J4 ecosystems. Designed to meet strict Original Engineering standards, this 200W motor delivers exceptional torque density and rapid acceleration, making it a critical component for automated production lines requiring absolute positioning accuracy. The S100 designation indicates a specialized configuration, while the integrated oil seal ensures robust protection in demanding environments. Ensuring Technical Compatibility with advanced Mitsubishi motor drivers, this unit optimizes machine cycle times and reduces operational latency.
Technical Specifications:
Manufacturer: Mitsubishi Electric
Series: MELSERVO HG-KN
Model Number: HG-KN23J-S100
Rated Output: 200 W (0.2 kW)
Rated Speed: 3000 r/min
Maximum Speed: 6000 r/min
Rated Torque: 0.64 N·m
Maximum Torque: 1.9 N·m
Encoder Resolution: 22-bit absolute/incremental (4,194,304 pulses/rev)
Voltage Class: 200V AC
Inertia: Low Inertia
Protection Rating: IP65 (excluding shaft-through portion)
Oil Seal: Equipped (J-specification)
Operating Temperature: 0°C to 40°C
Weight: 1.0 kg
Industrial Application:
The HG-KN23J-S100 is specifically optimized for high-throughput semiconductor wafer handling and surface-mount technology (SMT) pick-and-place machines. In these scenarios, the low-inertia rotor allows for instantaneous acceleration and deceleration, directly minimizing settling time. The 22-bit high-resolution encoder guarantees sub-micron positioning accuracy, preventing component misalignment during rapid indexing operations. The factory-installed oil seal protects the internal stator and encoder from cutting fluids and micro-particulates common in CNC auxiliary axes.
Lifecycle and Procurement:
Manufactured with industrial-grade neodymium magnets and high-grade copper windings, this servo motor ensures a prolonged operational lifespan under continuous duty cycles. We maintain optimized supply chain logistics to ensure a competitive Lead Time, minimizing costly downtime and ensuring seamless integration into your existing motion control architecture.
Key Attributes
Model Number: HG-KN23J-S100
Place of Origin: Japan
Brand Name: Mitsubishi
Warranty: 3 months ~ 1 year
Product name: Servo Motor
Application: Industrial control automation
Rated torque(N.m): 0.64
Rated power(kw): 0.2
Condition: 100% New Original
Package: Original Package
Shipping term: TNT DHL FEDEX EMS UPS
Warranty: 1 Year
Certification: Ccc,ce
Packaging and Delivery
Selling Units: Single item
Single package size: 60X50X40 cm
Single gross weight: 1.000 kg
