$7.86

SKU: 878322797766 Brand:

Description

The KAKU KA1238LA2 is a high-performance axial fan engineered for continuous thermal management in demanding environments. Utilizing a dual ball bearing system, this model ensures superior rotational stability and a significantly extended lifecycle compared to sleeve bearing alternatives. The die-cast aluminum frame provides structural rigidity and acts as a secondary heat sink, while the aerodynamically optimized PBT blades maximize static pressure for efficient cooling through dense internal components.

Manufacturer: KAKU
Model Number: KA1238LA2
Product Category: Industrial Axial Cooling Fan

Technical Specifications:
Frame Size: 120 x 120 x 38 mm
Bearing Type: High-Precision Dual Ball Bearing
Rated Voltage: 220-240V AC
Frequency: 50/60 Hz
Rated Current: 0.05 / 0.05 A
Input Power: 11 / 10 W
Rated Speed: 2000 / 2300 RPM
Airflow Volume: 60 / 72 CFM
Static Pressure: 3.3 / 4.1 mmH2O
Noise Level: 34 / 39 dB(A)
Frame Material: Die-Cast Aluminum Alloy (Black Coating)
Impeller Material: Reinforced PBT Thermoplastic (UL94V-0)
Insulation Resistance: 500MΩ at 500V DC
Dielectric Strength: 1500V AC for 1 minute
Operating Temperature: -20°C to +70°C
Expected Service Life: 50,000 Hours at 40°C
Weight: 530g
Termination: Lead Wire or Terminal Type (Model Dependent)

Industrial Application:
This unit is specifically designed for integration into server racks, CNC control cabinets, and power supply enclosures. The KA1238LA2 solves critical overheating issues in enclosed industrial systems where Technical Compatibility with 230V AC power grids is required. Its low current draw (0.05A) allows for multi-fan array configurations without overloading control circuits.

Quality Assurance and Logistics:
Condition: Original Engineering, Factory Sealed
Packaging: Industrial Bulk / Individual Box
Lead Time: Immediate Dispatch Available
Compliance: CE Certified, RoHS Compliant

KA1238LA2 Kaku 220-240VAC fan

KA1238LA2 Kaku 220-240VAC fan

KA1238LA2 Kaku 220-240VAC fan

KA1238LA2 Kaku 220-240VAC fan

KA1238LA2 Kaku 220-240VAC fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
