Description

The KAKU KA1525HA2 is a premium industrial-grade AC axial cooling fan engineered for high-efficiency thermal management in demanding environments. Utilizing Original Engineering principles, this unit delivers exceptional airflow to safeguard critical electronic components from thermal degradation.

Technical Specifications
Brand: KAKU
Model: KA1525HA2
Dimensions: 150 x 150 x 50 mm
Rated Voltage: 220V AC
Frequency: 50/60 Hz
Input Power: 38 W
Airflow: 5.38 m³/min
Bearing System: Dual Ball Bearing
Termination: Lead Wire
Frame Construction: Die-cast Aluminum with Black Paint
Impeller Material: Thermoplastic PBT (UL94V-0)
Operating Temperature: -20°C to +70°C
Acoustic Noise: 55 dB(A) ± 10%
Weight: 0.85 kg
Dielectric Strength: 1500V AC for 1 minute
Insulation Resistance: 500V DC / 100 MΩ Min
Protection Rating: Impedance Protected

Application Scenario
This high-velocity cooling fan is specifically designed for integration into industrial control cabinets, CNC machinery chassis, and telecommunications enclosures. The robust dual ball bearing system ensures a prolonged operational lifespan even in continuous-duty applications. Its precise Technical Compatibility allows for direct drop-in replacement in standard 150mm mounting configurations, effectively resolving localized heat accumulation in densely packed electrical panels.

Procurement and Lifecycle
Sourced directly to guarantee authenticity, this component offers a reliable solution for maintenance and OEM production. We maintain an optimized Lead Time to minimize facility downtime and support continuous industrial operations.

KA1525 HA2 New 15050/220V clamping ball

KA1525 HA2 New 15050/220V clamping ball

KA1525 HA2 New 15050/220V clamping ball

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
