Mdexx 2CF4564-1NA91-2JV8 380V AC Compressor Fan

Mdexx 2CF4564-1NA91-2JV8 380V AC Compressor Fan

$2,739.00

SKU: 62154547210 Brand:

Description

The Mdexx 2CF4564-1NA91-2JV8 is a heavy-duty AC axial cooling fan engineered specifically for industrial compressor and high-capacity chiller applications. Manufactured under strict Original Engineering standards, this unit ensures optimal thermal management for continuous-duty machinery. Designed to operate on a 380V AC 3-phase power supply, it delivers high-volume airflow to prevent thermal overload in critical drive systems and compressor enclosures.

Technical Specifications
Manufacturer: Mdexx
Model Number: 2CF4564-1NA91-2JV8
Equipment Type: Axial Compressor Cooling Fan
Nominal Voltage: 380V AC ±10%
Phase: 3-Phase
Frequency: 50/60 Hz
Power Consumption: 0.85 kW
Rated Current: 1.8 A
Rotational Speed: 1420 RPM
Maximum Airflow: 7500 m³/h
Protection Rating: IP55
Insulation Class: F (155°C)
Operating Temperature Range: -25°C to +60°C
Impeller Material: Die-cast Aluminum
Housing Material: Corrosion-resistant coated steel
Weight: 15.2 kg

Application & Integration
This cooling fan is primarily deployed in industrial rotary screw compressors, large-scale HVAC chillers, and power electronics cabinets. Its high-efficiency aerodynamic blade design minimizes acoustic noise while maximizing static pressure, solving the critical problem of heat dissipation in densely packed mechanical rooms. The IP55 rating ensures robust protection against dust and water ingress, making it suitable for harsh manufacturing environments.

Procurement & Lifecycle Value
Ensuring Technical Compatibility with legacy Siemens and current Mdexx 2CF series installations, this fan serves as a direct drop-in replacement to minimize system downtime. We maintain optimized supply chain logistics to provide a competitive Lead Time for urgent maintenance requirements. Routine inspection of the motor bearings and impeller balance is recommended to maximize the operational lifespan of the component.

Key Attributes
Mounting: Free Standing
Voltage: 380v
Blade Material: Cast Iron
Customized support: OEM, ODM
Warranty: 1 Year
After-sales Service Provided: Online support
Model number: 2CF4564-1NA91-2JV8
Place of origin: Germany
Brand name: Mdexx
Nominal voltage: 380V
Bearing Type: Ball Bearing
Power consumption: 3000W
Speed: 1650 (r/min)
Current: 1.7(A)
Frequency: 50~60Hz
Air flow: 1.2KG m3/h
Type: Centrifugal Fan

Packaging and Delivery
Selling Units: Single item
Single package size: 75X75X65 cm
Single gross weight: 68.000 kg

Mdexx 2CF4564-1NA91-2JV8 380V AC Compressor Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
