Description
Mitsubishi Electric MDS-D-V2-4040 is a high-performance, 2-axis AC servo drive unit engineered for advanced CNC machining applications. Utilizing high-speed optical communication, this unit ensures precise multi-axis synchronization and dynamic motor control.
Technical Specifications:
Manufacturer: Mitsubishi Electric
Series: MDS-D Series
Model Number: MDS-D-V2-4040
Number of Axes: 2-Axis Control
Rated Output Current (Axis 1): 40A
Rated Output Current (Axis 2): 40A
Input Voltage: 3-phase 200-230VAC (supplied via MDS-D-CV power supply)
Control Architecture: High-speed optical communication network
Feedback Resolution: High-resolution absolute/incremental encoder support
Cooling Method: Forced air cooling with internal fan
Operating Temperature: 0°C to +55°C
Storage Temperature: -20°C to +65°C
Ambient Humidity: 90% RH or less (non-condensing)
Vibration Resistance: 4.9 m/s²
Weight: 5.5 kg
System Architecture and Integration:
The MDS-D-V2-4040 is designed for seamless integration with Mitsubishi M700V, M70V, and E70 series CNC controllers. The dual-axis configuration optimizes electrical cabinet space while maintaining independent, high-fidelity control loops for each servo motor. It features advanced regenerative braking management when paired with the appropriate power supply unit, enhancing overall energy efficiency. Technical Compatibility is guaranteed when utilizing Original Engineering guidelines for optical bus connections and servo motor pairing.
Industrial Application:
This servo drive unit solves critical synchronization challenges in high-precision metal cutting, milling, and turning operations. In multi-axis CNC machining centers, the MDS-D-V2-4040 manages rapid positioning and complex interpolation with near-zero tracking delay. Its robust thermal management and high-speed current control loop make it strictly necessary for continuous, heavy-duty manufacturing environments where thermal drift and contouring errors must be eliminated.
Procurement and Lifecycle:
Condition: Brand New Original
Lead Time: Optimized for rapid global dispatch to minimize downtime
Lifecycle Status: Factory supported component
Installation: Direct plug-and-play replacement for existing MDSDV24040 modules
Key Attributes
Place of Origin: Japan
Model Number: MDS-D-V2-4040
Brand Name: Mitsubishi
Condition: 100% Original
Warranty: 1Year for new,3months for used
Delivery time: 3-5 Days
Packing: Package Carton
MOQ: 1Piece
Payment Method: All terms are accepted
Packaging and Delivery
Selling Units: Single item
