$366.00

SKU: 10000016864193 Brand:

Description

The Mitutoyo 500-153-30 is a high-precision AOS Absolute Digimatic Caliper engineered for rigorous industrial metrology and quality assurance applications. Utilizing Mitutoyo’s Original Engineering, this instrument features an Advanced Onsite Sensor (AOS) electromagnetic induction linear encoder. This technology ensures maximum resistance to environmental contaminants such as dirt, oil, and water, maintaining flawless accuracy in harsh workshop conditions.

Technical Specifications:
Brand: Mitutoyo
Model Number: 500-153-30
Measuring Range: 0 – 300 mm
Resolution: 0.01 mm
Accuracy: ±0.03 mm
Sensor Technology: AOS Electromagnetic Induction
System: ABSOLUTE (Retains origin point indefinitely)
Material: Hardened Stainless Steel
Data Output: SPC (Statistical Process Control) Compatible
Display Type: High-contrast LCD
Power Supply: 1x SR44 Silver Oxide Button Cell
Battery Life: Approx. 18,000 hours under normal use
Max Response Speed: Unlimited
Weight: 350 g

Industrial Application:
This caliper is specifically designed for CNC machining centers, automotive manufacturing, and aerospace quality control where precision dimensional verification is critical. The integrated SPC data output function ensures seamless Technical Compatibility with automated quality management systems, allowing for real-time data logging and statistical analysis without manual transcription errors.

Procurement and Lifecycle:
Manufactured to exact OEM standards, the 500-153-30 guarantees long-term reliability and calibration stability. Please contact our technical sales team to confirm current Lead Time and availability for bulk facility integration.

Key Attributes
Place of origin: Japan
Model number: 500-153-30
Brand name: Mitutoyo
Customized support: OEM, ODM
Warranty: 1 years
Measurement Range: 0 to 300 mm
Accuracy: ±0.03 mm
Zero Button: Yes
Display Type: LCD
Graduation Measurements: Millimeters
Material: Stainless steel
Approvals: IP67

Packaging and Delivery
Selling Units: Single item
Single package size: 32X18X13 cm
Single gross weight: 2.000 kg
