Description
Manufacturer: Yaskawa Electric Corporation
Series: Sigma Series SGM
Model Number: SGM-08U2HA12
Product Category: AC Servo Motor
Technical Specifications:
Rated Output: 750 W
Rated Torque: 2.39 Nm
Peak Torque: 7.16 Nm
Rated Speed: 3000 rpm
Maximum Speed: 4500 rpm
Rated Current: 4.4 A
Input Voltage: 200V AC
Encoder Resolution: 17-bit Incremental Encoder (131,072 pulses/rev)
Insulation Class: Class B
Enclosure Rating: IP55 (excluding shaft opening)
Shaft Type: Straight with Keyway
Brake Option: No Brake
Weight: 3.5 kg
Mechanical Dimensions:
Frame Size: 80 mm x 80 mm
Shaft Diameter: 14 mm
Total Length: 157 mm
Operational Environment:
Ambient Temperature: 0 to +40 °C
Ambient Humidity: 20% to 80% RH (non-condensing)
Storage Temperature: -20 to +60 °C
Vibration Resistance: 49 m/s²
Industrial Application and Integration:
The Yaskawa SGM-08U2HA12 is engineered for high-precision motion control within CNC machining centers, automated assembly lines, and high-speed packaging machinery. Its low-inertia design allows for rapid acceleration and deceleration cycles, critical for reducing cycle times in pick-and-place operations. The 17-bit incremental encoder ensures high-resolution positioning accuracy, mitigating cumulative error in complex multi-axis synchronization. Technical Compatibility is guaranteed when paired with Yaskawa SGD series servo drives, maintaining Original Engineering standards for system stability and thermal efficiency. This model is a critical component for maintaining the lifecycle value of legacy industrial automation systems where high torque density and compact form factors are required.
Key Attributes
Place of Origin: Japan
Brand Name: Fanuc
Communication Interface: Ethernet
Condition: 100% Original Brand
