$22.86

SKU: 742807551648 Brand:

Description

The Sanyo Denki San Ace 172 series, specifically model 9EB5748P5K03, is a high-performance industrial cooling solution engineered for critical infrastructure and outdoor telecommunications environments. This unit is a specialized 172mm x 150mm x 51mm side-cut fan designed for high static pressure requirements and extreme environmental resilience.

Technical Specifications:
Manufacturer: Sanyo Denki
Series: San Ace 172
Model Number: 9EB5748P5K03
Nominal Voltage: 48V DC
Operating Voltage Range: 36V to 72V DC
Rated Current: 1.1A
Rated Input: 52.8W
Rated Speed: 5,500 RPM
Maximum Airflow: 8.5 m³/min (300 CFM)
Maximum Static Pressure: 420 Pa (1.68 inchH2O)
Sound Pressure Level: 64 dB(A)
Bearing Type: Dual Ball Bearing
Expected Life: 40,000 hours at 60°C / 70,000 hours at 40°C
Ingress Protection Rating: IP68 (Dust-tight and protected against continuous immersion in water)
Weight: 820g

Mechanical and Material Data:
Frame Material: Aluminum Die-cast
Impeller Material: Plastic (UL 94V-0)
Dimensions: 172mm x 150mm x 51mm
Termination: 4-wire lead (Red: +, Black: -, Yellow: Sensor/Tachometer, Brown: PWM Control)
Control Logic: Pulse Width Modulation (PWM) for dynamic speed regulation

Environmental and Safety Standards:
Operating Temperature: -20°C to +70°C
Storage Temperature: -30°C to +70°C
Certifications: UL, CSA, TÜV, RoHS Compliant
Protection Features: Locked rotor burnout protection, Reverse polarity protection

Industrial Application and Compatibility:
This model is primarily utilized as a critical thermal management component in Huawei server racks and outdoor base stations. The IP68 rating ensures Technical Compatibility with equipment exposed to high humidity, salt spray, or direct water contact. Its high static pressure capability allows it to push air through high-density heat sinks and tightly packed electronic enclosures where standard fans would fail. This is an Original Engineering spare part, ensuring seamless integration with existing PWM control logic systems to maintain optimal thermal equilibrium and prevent system downtime. Lead Time for this specialized industrial component is subject to current global logistics availability for authentic Sanyo Denki stock.

9EB5748P5K03 Sanyo Huawei Server Power Supply fan

9EB5748P5K03 Sanyo Huawei Server Power Supply fan

9EB5748P5K03 Sanyo Huawei Server Power Supply fan

9EB5748P5K03 Sanyo Huawei Server Power Supply fan

9EB5748P5K03 Sanyo Huawei Server Power Supply fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
