Description
The Bosch GTC 600 C is a high-resolution infrared thermal imager designed for industrial diagnostics, electrical inspection, and HVAC system analysis. Unlike the entry-level GTC 400 C, the GTC 600 C features an enhanced sensor array providing superior thermal detail for identifying thermal bridges, overheating components, and insulation defects in complex environments.
Technical Specifications:
Sensor Resolution: 256 x 192 Pixels (49,152 points)
Thermal Sensitivity (NETD): <50 mK
Measuring Range: -20 °C to +600 °C
Measuring Accuracy: ±2.0 °C or ±2.0%
Field of View (FOV): 45° x 35°
Focus Distance: Fixed (≥0.3 m)
Display Type: 3.5 inch TFT LCD
Visual Camera Resolution: 5 Megapixels
Data Transfer: Wi-Fi, USB-C®, Bluetooth® Low Energy
Internal Memory: 600 Images (JPEG + Metadata)
Ingress Protection: IP54 (IEC 60529)
Drop Protection: 2.0 Meters
Power Source: 12V Li-ion Battery or 4x 1.5V LR6 (AA)
Operating Temperature: -10 °C to +45 °C
Weight: 0.64 kg
Original Engineering and System Integration:
This unit utilizes Bosch Measuring Master and GTC Transfer Software for seamless documentation. The integrated voice note function allows for hands-free annotation during site inspections. The device supports high Technical Compatibility with existing Bosch 12V Professional battery platforms, ensuring minimal downtime in the field.
Industrial Application Scenario:
In large-scale electrical distribution maintenance, the GTC 600 C is utilized to detect micro-variations in terminal block temperatures. While standard imagers may miss small-scale heat signatures due to low resolution, the 256×192 sensor ensures that high-resistance connections are identified before catastrophic system failure occurs. The wide temperature range up to 600 °C makes it suitable for monitoring industrial kilns and high-load mechanical bearings.
Logistics and Availability:
Lead Time: Typically available for immediate dispatch from global distribution centers.
Condition: Factory New, Original Engineering Standards.
Key Attributes
Thermal color palettes: 5 Color Palettes
Thermal Image Pixel: 256 x 192
Thermal Sensitivity: 50 mk
Place of Origin: Malaysia
Display resolution: 256 x 192
Field of View: 25° x 19°
Image Frequency: 9 Hz
Model Number: GTC600C
Brand Name: Bosch
Resolution of Infrared Sensor: 256 x 192
Field of View (FOV): 45 x 35°
Temperature Measurement Range: -20 to 600°C
Battery Life: 5 hours
Wireless Connectivity: WiFi
Display Resolution: 320 x 240
Dimensions: 233 x 95 x 63 mm
Weight: 0.7kg
Color: Blue
Packaging and Delivery
Selling Units: Single item
Single package size: 45X26X16 cm
Single gross weight: 2.000 kg
