UNI-T UT300A+ Customizable Infrared Thermometer UNI-T UT300S Non-Contact Thermometer

Description

Product Overview: UNI-T UT300A+ / UT300S Series Infrared Thermometers
Manufacturer: Uni-Trend Technology (China) Co., Ltd.
Product Category: Non-Contact Infrared Pyrometers

Technical Specifications: UT300A+
Temperature Range: -20°C to 400°C (-4°F to 752°F)
Accuracy: ±2.0°C or ±2%
Repeatability: ±0.5°C or ±0.5%
Distance to Spot Ratio (D:S): 10:1
Response Time: ≤500ms (95% of reading)
Spectral Response: 8μm to 14μm
Emissivity: 0.95 (Fixed)
Display Resolution: 0.1°C
Laser Type: Single Point Laser (Class 2)
Laser Power: <1mW
Laser Wavelength: 630nm to 670nm

Technical Specifications: UT300S
Temperature Range: -32°C to 400°C (-25.6°F to 752°F)
Accuracy: ±2.0°C or ±2%
Distance to Spot Ratio (D:S): 12:1
Emissivity: 0.10 to 1.00 (Adjustable)
Response Time: ≤500ms
Display Type: EBTN (Enhanced Black Twisted Nematic) LCD

Physical and Environmental Parameters
Power Source: 9V Battery (6F22) or 1.5V AAA (Model dependent)
Display Size: 22mm x 22mm
Product Color: Red and Grey
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Storage Temperature: -20°C to 60°C (-4°F to 140°F)
Operating Humidity: <90% RH (Non-condensing)
Drop Test Rating: 1 Meter
Weight: Approximately 185g
Dimensions: 153mm x 108mm x 40mm

Advanced Features and Logic
Data Hold: Automatic display retention after trigger release
Auto Power Off: 8-second inactivity shutdown for battery conservation
Backlight Control: Integrated toggle for low-light environments
Unit Selection: Switchable Celsius and Fahrenheit scales
MAX/MIN Mode: Real-time peak and valley tracking (UT300S)
High/Low Alarms: Visual and audible indicators for setpoint breaches

Industrial Application and Technical Compatibility
The UNI-T UT300 series is engineered for rapid thermal diagnostics in HVAC maintenance, electrical distribution inspection, and automotive troubleshooting. The 10:1 and 12:1 D:S ratios allow for safe measurement of energized components or high-speed rotating machinery. The adjustable emissivity on the UT300S model is critical for accurate measurement across varying surface materials such as oxidized metals or polished polymers, ensuring Original Engineering precision in diverse manufacturing environments.

OEM and ODM Support
Customizable configurations are available for bulk procurement, including private labeling, specialized temperature ranges, and custom packaging. Contact technical sales for Lead Time estimates and high-volume integration requirements.

Key Attributes
Type: Infrared Thermometer
Place of origin: Guangdong, China
Model number: UT300A+
Brand name: UNI-T
Customized support: OEM, ODM
Material: Plastics
Warranty: 1 years
Temperature range: -20℃~400℃
Accuracy: ±2°C or ±2%
D:S ratio: 10:1
Response time: ≤500ms (95% of reading)
Spectral response: 5.5um~14um
Laser power: < 1mW
Theory: Infrared Thermometer

Packaging and Delivery
Selling Units: Single item
Single package size: 28X20X15 cm
Single gross weight: 1.500 kg
