Delta Inverter VFD49AMS23ANSAA

Description

Delta Electronics MS300 Series Compact Sensorless Vector Control Drive
Model Number: VFD49AMS23ANSAA

TECHNICAL PROFILE & SPECIFICATIONS
Manufacturer: Delta Electronics
Series: MS300
Model Code Breakdown: VFD (Variable Frequency Drive) 49A (49.0 A Rated Output) M (MS300 Series) S (Standard) 23 (3-Phase 230V Input) A (IP20) N (No Built-in EMC Filter) S (Built-in Braking Chopper) A (Standard Model)
Input Voltage: 3-Phase 200 V AC to 240 V AC (-15% / +10%)
Input Frequency: 50/60 Hz (±5%)
Rated Output Current: 49.0 A (Heavy Duty / Normal Duty matched)
Applicable Motor Capacity: 11 kW (15 HP)
Output Frequency Range: 0.0 to 599.00 Hz
Control Modes: V/f Control, Sensorless Vector Control (SVC), Deceleration Energy Backup (DEB), Permanent Magnet Motor Control (SPM/IPM)
Overload Capacity: 120% for 60 seconds (Normal Duty), 150% for 60 seconds (Heavy Duty), 200% for 3 seconds
Braking Unit: Integrated Dynamic Braking Chopper
EMC Filter: None (External filter option supported)
Enclosure Rating: IP20 / UL Open Type (Frame E)
Cooling Method: Fan Cooled with speed control logic
Operating Temperature: -20°C to +50°C (nominal, up to +60°C with derating)
Storage Temperature: -40°C to +85°C
Ambient Humidity: 90% RH or less (non-condensing)
Analog Inputs: 2 Channels (0 to 10 V, 4 to 20 mA switchable)
Digital Inputs: 7 Multi-function inputs (NPN/PNP selectable)
Analog Outputs: 1 Channel (0 to 10 V)
Relay / Digital Outputs: 1 Multi-function relay output (SPDT), 2 Multi-function photocoupler outputs
Communication Interface: Built-in RS-485 (Modbus RTU/ASCII), Mini-USB programming port
Expansion Communication Options: EtherNet/IP, Modbus TCP, CANopen, DeviceNet, PROFIBUS DP
Compliance and Certifications: CE, UL, cUL, RoHS, REACH

SYSTEM ARCHITECTURE & INTEGRATION
The VFD49AMS23ANSAA drive utilizes optimized space-vector modulation to drive both standard induction and high-efficiency permanent magnet synchronous motors. Built-in PLC functionality (up to 2k steps) eliminates the requirement for external micro-controllers in distributed logic loops. Dynamic braking torque is managed via the integrated braking transistor, allowing direct connection to an external braking resistor for rapid deceleration cycles. Compact frame architecture supports zero-clearance side-by-side mounting in industrial control panels.

CRITICAL APPLICATION SCENARIOS
Engineered specifically for high-torque 230V industrial infrastructure such as high-inertia industrial centrifuges, packaging winders/unwinders, automated machine tool spindles, conveyor feeder lines, and positive displacement pumps where robust low-frequency torque output (up to 200% at 0.5 Hz in vector mode) and high operational stability under dynamic load swings are required.

COMMERCIAL & SUPPLY SPECIFICATIONS
Original Engineering: Authentic Delta Electronics hardware featuring factory-calibrated firmware and standard industrial warranties.
Technical Compatibility: Direct replacement across machinery platforms operating 200-240V 3-phase motor architectures requiring up to 49A continuous current delivery.
Lead Time: Inquire for active inventory status, batch shipments, and expedited global dispatch timelines.

Key Attributes
Place of Origin: Taiwan, China
Brand Name: Delta
Communication Interface: Other
Product Name: Inverter
Condition: Original new
Warranty: 12 Months
Stock: Available
Shipping terms: All terms are accepted
Payment terms: All terms are accepted
Lead Time: 1-2 Days
Delivery Time: 3-5 Days
Package: Carton packing
MOQ: 1 Piece

Packaging and Delivery
Selling Units: Single item
Single package size: 60X60X30 cm
Single gross weight: 2.000 kg
