Druck Electronic DPI612 Flexible Range Pressure Calibrators Process Calibrators Series DPI610 DPI613

Description

The Druck DPI612 Flexis series represents the pinnacle of fully self-contained pressure test and calibration systems. Engineered as the direct evolutionary successor to the legacy DPI610 and DPI613 series, this advanced process calibrator integrates pressure generation, signal measurement, and loop power into a single, highly portable architecture. The flexible range capability is driven by interchangeable PM620 pressure modules, allowing technicians to reconfigure the unit in the field without specialized tools or factory recalibration.

At the core of the DPI612 architecture is a highly efficient mechanical pressure generation system available in three distinct bases: pFlex (low-pressure pneumatic), pFlexPro (high-pressure pneumatic), and hFlex (hydraulic). This system eliminates the need for external gas cylinders or hand pumps. The integrated electrical suite provides simultaneous measurement and sourcing of mA, V, and switch contacts, complete with 24V loop power, ensuring seamless Technical Compatibility with modern smart transmitters and analog gauges.

Technical Specifications:
Model Series: Druck DPI612 Flexis
Pressure Range (Pneumatic): -0.95 to 20 bar (pFlex) / -0.95 to 100 bar (pFlexPro)
Pressure Range (Hydraulic): 0 to 1000 bar (hFlex)
Pressure Accuracy: ±0.005% FS (dependent on PM620 module selection)
Electrical Measurement: ±0.015% of reading (mA, V, mV)
Display: 4.3-inch high-resolution color touchscreen
Operating Temperature: -10°C to 50°C
Ingress Protection: IP55
Weight: 2.7 kg (pFlex) / 3.4 kg (pFlexPro) / 4.7 kg (hFlex)
Dimensions (pFlex): 350 mm x 170 mm x 145 mm
Data Storage: 8GB internal memory
Connectivity: USB, WiFi (optional)
Certifications: CE, RoHS

Industrial Application:
The DPI612 is engineered for critical field calibration in petrochemical refineries, power generation facilities, and offshore platforms. In a typical scenario involving the verification of differential pressure transmitters across a custody transfer pipeline, the technician utilizes the pFlexPro base to rapidly generate 100 bar of pneumatic pressure while simultaneously monitoring the 4-20mA output. The system’s rapid thermal stabilization and leak-tight volume adjuster ensure precise setpoint control, drastically reducing downtime during scheduled plant outages.

Procurement and Lifecycle Value:
Maintaining Original Engineering standards is critical for process safety and audit compliance. The DPI612 ensures backward Technical Compatibility with existing PM620 module inventories, maximizing return on investment for facilities upgrading from the legacy DPI610 series. With optimized global supply chains, we provide accurate Lead Time estimates to keep your maintenance schedules on track, delivering authentic Druck calibration technology directly to your facility.

Key Attributes
Place of origin: China
Customized support: OEM, ODM
Brand name: Druck
Warranty: 1 years
Model number: DPI612
Product name: Druck
Model: DPI612
Maximum Pressure Measurement: 20bar / 100bar
Pressure Port Type: Gauge
Maximum Operating Temperature: +50°C
Minimum Operating Temperature: -10°C
Dimensions: 350 x 170 x 145mm
Weight: 3.5kg
Power: Electronic

Packaging and Delivery
Selling Units: Single item
Single package size: 45X28X20 cm
Single gross weight: 4.500 kg
