Description
The Fanuc A02B-0166-C261 (incorporating PCB A20B-2002-0130) is a high-performance 9.5-inch Monochrome LCD/MDI Unit designed for seamless integration with Fanuc Series 16, 18, and 21 Control Systems. This unit serves as the primary human-machine interface (HMI), providing critical diagnostic data and G-code programming capabilities for CNC machinery.
Technical Specifications:
Manufacturer: Fanuc
Part Number: A02B-0166-C261
Internal PCB Assembly: A20B-2002-0130
Display Type: Monochrome Liquid Crystal Display (LCD)
Screen Size: 9.5 Inch Diagonal
Interface Type: MDI (Manual Data Input) with integrated softkeys
Input Voltage: 24V DC (±10%)
Power Consumption: Approximately 15W
Communication Protocol: Fanuc Serial Interface
Video Signal: Digital TTL
Operating Temperature: 0°C to 45°C
Storage Temperature: -20°C to 60°C
Humidity Range: 10% to 90% RH (non-condensing)
Weight: 2.45 kg
Dimensions: 260mm x 190mm x 65mm
Original Engineering and Technical Compatibility:
This unit is engineered to replace legacy CRT monitors, offering superior clarity and reduced heat dissipation. It is fully compatible with Fanuc 16-M, 16-T, 18-M, 18-T, 21-M, and 21-T control variations. The A20B-2002-0130 control board ensures high-speed signal processing and low-latency screen refreshes, maintaining the precision required for high-speed machining environments.
Industrial Application:
The A02B-0166-C261 is critical in precision milling and turning centers where real-time monitoring of axis coordinates and spindle speeds is essential. Its rugged construction resists electromagnetic interference (EMI) and vibration, making it suitable for heavy-duty automotive and aerospace manufacturing floors.
Inventory and Logistics:
Condition: Refurbished / New Surplus available
Lead Time: Ships within 24-48 hours for stock items
Quality Assurance: Fully tested on dedicated Fanuc test rigs prior to dispatch
Key Attributes
Place of Origin: Japan
Model Number: A02B-0166-C261
Brand Name: Fanuc
Product Name: Fanuc LCD Panel
Condition: Original
Warranty: 1 Year for new,3 months for used
Stock: Available
Shipping terms: All terms are accepted
Payment terms: All terms are accepted
Lead Time: 1-2 Days
Delivery Time: 3-5 Days
Package: Carton packing
MOQ: 1 Piece
Packaging and Delivery
Packaging Details: Standard export cartons or wooden boxes.
Port of dispatch: Shenzhen,Guangzhou,Hongkong
Selling Units: Single item
