Description
The FLIR K2 is a professional-grade Fire Protection Thermal Imaging Camera (TIC) engineered specifically for structural firefighting, search and rescue, and overhaul operations. Utilizing Original Engineering from FLIR, this compact and ruggedized thermal imager integrates proprietary Multi-Spectral Dynamic Imaging (MSX) technology, which overlays key details from the built-in visible light camera onto the thermal image in real-time. This enhances structural visibility and situational awareness in zero-visibility, smoke-filled environments. The K2 is designed for seamless Technical Compatibility with standard firefighter gear, featuring a simplified single-button interface operable with heavy tactical gloves. Built to withstand extreme environmental stressors, the unit survives a 2-meter drop onto concrete and maintains an IP67 enclosure rating. Standard Lead Time applies for fleet deployments and replacement cycles.
Technical Specifications:
Manufacturer: FLIR Systems
Model Number: K2
Equipment Type: Thermal Imaging Camera (TIC)
IR Resolution: 160 x 120 pixels (19200 pixels)
Thermal Sensitivity (NETD): Less than 100 mK at 30°C
Field of View (FOV): 47° x 35°
Image Frequency: 9 Hz
Display: 3-inch backlit LCD (320 x 240 pixels)
Temperature Range: -20°C to +150°C (Mode 1) / 0°C to +500°C (Mode 2)
Image Modes: TI Basic, Black and White, Fire, Search and Rescue, Heat Detection
MSX Enhancement: Yes, built-in visual camera
Drop Test Rating: 2 meters onto concrete
Enclosure Rating: IP67 (waterproof and dustproof)
Operating Temperature: -20°C to +55°C (continuous) / +85°C for 15 minutes / +150°C for 10 minutes
Battery Type: Li-ion, rechargeable
Operating Time: Approximately 4 hours at 25°C
Weight: 0.7 kg (with battery)
Dimensions: 250 mm x 105 mm x 90 mm
Application Scenario:
The FLIR K2 is deployed in active fire suppression and overhaul phases. Its 500°C maximum temperature rating and MSX-enhanced 19200-pixel resolution allow fire crews to rapidly identify structural hotspots, locate trapped victims through dense smoke, and verify fire extinguishment. The robust IP67 housing and high-heat tolerance ensure continuous operation during critical interior attacks, minimizing the risk of thermal disorientation and improving overall operational safety.
Key Attributes
Place of Origin: Estonia
Model Number: K2
Brand Name: FLIR
Product name: FLIR Thermal Imager
Model: K2
IR Resolution: 160 x 120 pixels
Image Frequency: 9 Hz
Start-up time from sleep mode: <10 seconds
Start-up Time: <30 seconds (IR image, no GUI)
Object temperature range: 32 to 932°F( 0 to 500°C)
Sensitivity: Minimum 10 lux
Built-in digital camera: 640 x 480 pixels
Encapsulation: IP 67 (IEC 60529)
Packaging and Delivery
Packaging Details: Cardboard box
Selling Units: Single item
Single package size: 45X31X14 cm
Single gross weight: 2.500 kg
