Fluke 324 True RMS Clamp Meter with Temperature Measuring DC Current Complementing Fluke 323 325 Digital Clamp Meters

Description

The Fluke 324 is a precision-engineered diagnostic tool designed for commercial and residential electricians. As the mid-range model in the 320 Series, it bridges the gap between the 323 and 325 by adding temperature and capacitance measurement capabilities, making it essential for HVAC and electrical troubleshooting.

Technical Specifications:
AC Current Range: 40.00 A / 400.0 A
AC Current Accuracy: 2% ± 5 digits (45 Hz to 400 Hz)
AC Voltage Range: 600.0 V
AC Voltage Accuracy: 1.5% ± 5 digits
DC Voltage Range: 600.0 V
DC Voltage Accuracy: 1.0% ± 5 digits
Resistance Range: 400.0 Ω / 4000 Ω
Resistance Accuracy: 1.0% ± 5 digits
Continuity Threshold: ≤ 30 Ω
Capacitance Range: 100.0 μF to 1000 μF
Contact Temperature Range: -10.0 °C to 400.0 °C (14 °F to 752 °F)
True-RMS Sensing: Yes
Data Hold Function: Yes
Backlight Display: Yes

Mechanical and Environmental Data:
Maximum Wire Diameter: 30 mm (600 MCM)
Dimensions: 207 mm x 75 mm x 34 mm
Weight: 208 g
Operating Temperature: -10 °C to +50 °C
Storage Temperature: -30 °C to +60 °C
Operating Humidity: Non-condensing (< 10 °C), ≤ 90% RH (at 10 °C to 30 °C)
Safety Rating: CAT III 600 V, CAT IV 300 V
IP Rating: IP 40
Warranty: 2-Year Manufacturer Warranty

Industrial Application:
The Fluke 324 is optimized for verifying the presence of load current, AC voltage, and the continuity of circuits, switches, fuses, and contacts. Its True-RMS sensing ensures accurate measurements even on non-linear signals caused by electronic loads. The integrated temperature probe allows HVAC technicians to diagnose thermal issues in motors and electrical panels without carrying secondary instrumentation.

Logistics and Compliance:
Original Engineering: Fluke Corporation
Technical Compatibility: Compatible with TL75 Test Leads and Type K Thermocouples
Lead Time: Typically available for immediate dispatch
Certifications: CE, CSA, TUV

Key Attributes
Max. Ac Current: 40 to 400 A
Max. DC Current: 40 to 400 A
Measuring Voltage Range: 600 V
Place of Origin: China
Model Number: 324
Brand Name: Fluke
Dimensions: 34 x 75 x 207 mm
Display Type: Digital Only
Max. Ac Voltage: 600V
Max. DC Voltage: 600V
Measuring Capacitance Range: 0 to 1000uF
Measuring Current Range: 400 A
Measuring Inductance Range: ,
Measuring Resistance Range: 400 to 4000 Ω
Operating Temperature: -10 to 50°C
Parameters Measured: AC Voltage, DC Current
Weight: 210g
AC Current Range: 40 to 400 A
AC/DC Voltage Range: 600V
Resistance Range: 400 to 4000 Ω
Capacitance: 0 to 100 μF 100 to 1000 μF
AC Response: True RMS
Contact Temperature: 14 to 752°F (-10 to 400°C)
Category Rating: CAT III 600 V CAT IV 300 V
Weight: 210g

Packaging and Delivery
Selling Units: Single item
Single package size: 28X16X13 cm
Single gross weight: 2.000 kg
