Fluke TIS55+ Thermal Imager Frame Rate 256 X 192 Infrared Resolution

Description

The Fluke TiS55+ is an advanced diagnostic thermal imager engineered for frontline industrial maintenance and rigorous troubleshooting. Utilizing Fluke’s Original Engineering, this device captures highly accurate thermal data to identify temperature differentials in complex mechanical and electrical systems. The integration of manual focus allows technicians to isolate specific thermal anomalies in densely packed equipment cabinets, ensuring optimal diagnostic accuracy.

Technical Specifications:
Manufacturer: Fluke
Model Number: TiS55+
Infrared Resolution: 256 x 192 (49,152 pixels)
Temperature Measurement Range: -20 °C to 550 °C
Thermal Sensitivity (NETD): ≤ 40 mK at 30 °C
Field of View (FOV): 28° x 20°
Spatial Resolution (IFOV): 1.91 mRad
Frame Rate: 27 Hz / 9 Hz
Focus Mechanism: Manual Focus
Image Blending: Continuous IR-Fusion Technology
Display: 3.5-inch VGA Touchscreen LCD
Data Storage: Internal 4GB memory and 4GB micro SD card
Enclosure Rating: IP54
Drop Tolerance: 2.0 meters
Weight: 1.04 kg
Telemetry: Fluke Connect WiFi Compatibility

Industrial Application:
This thermal imager is critical for predictive maintenance in heavy industrial environments. In three-phase electrical systems, the TiS55+ detects micro-resistance and load imbalances. In mechanical drives, the 40 mK thermal sensitivity identifies early-stage bearing wear and gearbox friction. The manual focus ensures precise measurement of specific wire terminals or motor housings, preventing false readings from adjacent heat signatures.

Procurement Information:
The TiS55+ offers seamless Technical Compatibility with Fluke Connect software for automated asset tagging and reporting. Please verify current Lead Time requirements to ensure rapid deployment into your facility’s condition monitoring program.

Key Attributes
Thermal color palettes: Other
Place of Origin: United States
Model Number: TIS55+
Brand Name: Fluke
Infrared Resolution: 256 x 192 (49,152 pixels)
IFOV: 1.91 mRad
Focus System: Manual focus and 1 meter focus marker
Frame Rate: 9Hz
Temperature Range: -4 to 1022°F (-20 to 550°C)
Accuracy: ±2°C or 2%
Enclosure Rating: IP54
Weight: 2.27 kg
Theory: Infrared Thermometer
Temperature Control Accuracy: ±2°C or 2%

Packaging and Delivery
Selling Units: Single item
Single package size: 45X38X28 cm
Single gross weight: 4.500 kg
