Keithley 2601B Single Channel System SourceMeter SMU Electronic Measuring Instrument

Description

The Keithley 2601B is a highly integrated, single-channel System SourceMeter (SMU) designed for precision electronic measurement and high-throughput production testing. Engineered by Keithley Instruments, this unit combines a precision power supply, true current source, 6.5-digit multimeter, arbitrary waveform generator, and pulse generator into a single tightly synchronized instrument.

System Architecture and Integration:
The 2601B leverages proprietary Test Script Processor (TSP) technology, embedding complete test programs directly into the instrument’s non-volatile memory to eliminate PC bus communication delays. For scalable multi-channel applications, the TSP-Link interface enables seamless Technical Compatibility with other 2600B series instruments, creating a master/slave network that operates as a unified, high-speed system without mainframe constraints.

Technical Specifications:
Manufacturer: Keithley Instruments (Tektronix)
Model: 2601B
Instrument Type: Single-Channel System SourceMeter (SMU)
Max Voltage Source/Measure: ±40V
Max Current Source/Measure: ±3A DC, ±10A Pulsed
Maximum Output Power: 40W
Measurement Resolution: 6.5 Digits
Basic Accuracy: 0.015%
Communication Interfaces: GPIB, RS-232, USB, LXI Class C (Ethernet), TSP-Link
Embedded Logic: Test Script Processor (TSP)
Operating Temperature: 0°C to 50°C
Storage Temperature: -25°C to 65°C
Relative Humidity: 5% to 70% up to 50°C
Dimensions: 89 mm x 213 mm x 460 mm
Weight: 5.5 kg

Industrial Application:
The 2601B is purpose-built for semiconductor device characterization, I-V curve tracing, and highly automated production testing of active and passive components. Its ability to source up to 10A pulsed current makes it exceptionally suited for testing high-brightness LEDs, power MOSFETs, and transient voltage suppression devices where thermal management and precise timing are critical to preventing device degradation during the test cycle.

Procurement and Lifecycle:
Backed by Original Engineering standards, this SMU ensures long-term calibration stability and plug-and-play backward compatibility with legacy 2600A series code. We optimize our global supply chain to provide an accurate Lead Time for critical testing facility upgrades, ensuring minimal downtime for your high-volume manufacturing environment.

Key Attributes
Place of origin: China
Model number: 2601B
Brand name: Keithley
Customized support: OEM
Material: Iron
Power: Power supply
Size: 35 * 35 * 16cm
Warranty: 1 years
Number of Channels: 1 Channel
Maximum Curren: 3 / 10 A
Maximum Voltage: 40 V
Maximum Power: 40 W
Relative Humidity Range: 0-70%
Operating Temperature Range: 0-50°C

Packaging and Delivery
Selling Units: Single item
Single package size: 46X38X26 cm
Single gross weight: 4.000 kg
