Keysight DSOX1202A Digital Oscilloscope 70 MHz 2 Channel DSOX1204A

Description

Manufacturer: Keysight Technologies
Model: DSOX1202A
Series: InfiniiVision 1000 X-Series
Product Category: Digital Storage Oscilloscope
Bandwidth: 70 MHz
Analog Channels: 2
Max Sample Rate: 2 GSa/s
Max Memory Depth: 2 Mpts
Waveform Update Rate: 50,000 wfms/s
Vertical Resolution: 8 bits
Input Impedance: 1 MΩ ± 2% | 16 pF ± 3 pF
Input Coupling: DC, AC
Maximum Input Voltage: 300 Vrms, 400 Vpk
Time Base Range: 5 ns/div to 50 s/div
Trigger Types: Edge, Pulse Width, Video, Serial, Pattern
Serial Protocol Analysis: I2C, SPI, UART/RS-232, CAN, LIN (Standard)
Frequency Response Analysis: Bode plot (Standard)
Built-in Tools: Digital Voltmeter, Frequency Counter
Display: 7-inch WVGA LCD
Interface: USB 2.0 Hi-Speed Host, USB 2.0 Hi-Speed Device, LAN
Power Requirements: 100 to 240 VAC, 50/60 Hz
Operating Temperature: 0 °C to +50 °C
Storage Temperature: -40 °C to +70 °C
Dimensions: 314 mm x 165 mm x 130 mm
Weight: 3.2 kg
Certifications: IEC 61010-1:2010, CAN/CSA-C22.2 No. 61010-1-12

Technical Profile and Industrial Application: The Keysight DSOX1202A is a precision instrument featuring Original Engineering from the InfiniiVision 1000 X-Series, designed to deliver professional-grade measurement integrity. This model utilizes custom ASIC technology to achieve a 50,000 waveforms per second update rate, ensuring the capture of infrequent signal glitches and metastable states that compromise system reliability. In industrial automation and embedded design, the DSOX1202A provides critical Technical Compatibility with complex signal environments through its integrated hardware-based serial decoding and Frequency Response Analysis (Bode plots). This functionality is essential for characterizing power supply rejection ratios (PSRR) and control loop stability in DC-DC converters. The unit’s standard LAN connectivity allows for seamless integration into automated test sequences, reducing Lead Time in high-volume manufacturing verification. Its robust thermal management and high input voltage protection make it suitable for rigorous benchtop testing and field service applications where accuracy and durability are non-negotiable.

Key Attributes
Type: Digital Oscilloscope
Place of origin: China
Model number: DSOX1202A
Brand name: Keysight
Customized support: OEM, ODM
Warranty: 1 years
Product Name: Keysight Digital Oscilloscope
Model: DSOX1202A
Bandwidth: 70 MHz
Channels: 2
Sampling Rate: 2 GS/S
Memory: 2 MP [megapoints] (2048 kB)
Rise Time: 5 ns
Screen Size: 7 IN
Bits: 8

Packaging and Delivery
Packaging Details: Cardboard box
Port of dispatch: Shenzhen, China
Selling Units: Single item
