Description
The Keysight DSOX1204G is a professional-grade InfiniiVision 1000 X-Series digital storage oscilloscope engineered for precision signal analysis and embedded system debugging. Leveraging Keysight’s Original Engineering MegaZoom IV custom ASIC technology, this unit delivers uncompromising waveform visibility and measurement accuracy.
Model Decoding and System Architecture:
DSO: Digital Storage Oscilloscope
X: InfiniiVision X-Series Platform
1: 1000 Series Classification
2: 2 GSa/s Maximum Sampling Rate
04: 4 Analog Channels
G: Integrated 20 MHz WaveGen Function Generator
Technical Specifications:
Bandwidth: 70 MHz
Analog Channels: 4
Maximum Sample Rate: 2 GSa/s (half channel), 1 GSa/s (all channels)
Memory Depth: 2 Mpts
Waveform Update Rate: 200,000 wfms/s
Integrated Generator: 20 MHz WaveGen (Sine, Square, Ramp, Pulse, DC, Noise)
Display: 7-inch TFT LCD WVGA (800 x 480)
Vertical Resolution: 8 bits
Input Impedance: 1 MΩ ± 2% / 16 pF ± 3 pF
Connectivity: USB 2.0 Host/Device, LAN
Operating Temperature: 0°C to 50°C
Weight: 3.13 kg
Dimensions: 314 mm x 165 mm x 130 mm
Industrial Application and Technical Compatibility:
The DSOX1204G is specifically deployed in complex embedded system diagnostics, automotive serial bus decoding (CAN, LIN, I2C, SPI), and manufacturing quality assurance. The 200,000 wfms/s update rate allows engineers to capture infrequent, random glitches that standard oscilloscopes miss. The integrated 20 MHz WaveGen provides stimulus output for component testing, ensuring seamless Technical Compatibility across diverse test bench environments without requiring standalone signal generators.
Procurement and Lifecycle Value:
Designed for long-term reliability in rigorous testing environments, this instrument minimizes downtime and maximizes diagnostic throughput. Contact us to confirm current Lead Time and calibration certification options for your facility.
Key Attributes
Type: Digital Oscilloscope
Place of origin: China
Size: 35*20*25cm
Model number: DSOX1204G
Brand name: Keysight
Customized support: No
Warranty: 1 years
Bandwidth: 70 MHz
Channels: 4
Sampling Rate: 2 GS/S
Memory: 2 MP [megapoints] (2048 kB)
Rise Time: 5 ns
Screen Size: 7 IN
Unique Features: Includes 20 MHz function generator
Bits: 8
Mode: 70 MHz
Material: Plastic
Packaging and Delivery
Selling Units: Single item
Single package size: 48X38X28 cm
Single gross weight: 4.500 kg
