Lutron VB-8206SD Vibration Meter Testing Equipment

Description

The Lutron VB-8206SD is a professional-grade vibration meter and real-time data logger designed for precise mechanical condition monitoring. Engineered with Original Engineering standards by Lutron, this diagnostic instrument provides comprehensive measurement of acceleration, velocity, and displacement. Technical Compatibility is ensured across various industrial maintenance protocols through its strict adherence to ISO 2954 standards for vibration severity measurement. The system integrates an SD card data logger with a built-in clock and calendar, enabling seamless long-term condition monitoring and data exportation to spreadsheet software without requiring proprietary interface programs.

Industrial Application:
This testing equipment is critical for predictive maintenance programs in heavy manufacturing, petrochemical processing, and power generation. By capturing high-fidelity vibration signatures from rotating machinery such as industrial pumps, HVAC chillers, and turbine generators, reliability engineers can detect early-stage bearing wear, rotor unbalance, and structural resonance. The separate magnetic base probe allows for secure, repeatable measurements on curved motor housings, preventing catastrophic equipment failure and minimizing unplanned downtime.

Technical Specifications:
Measurement Modes: Acceleration, Velocity, Displacement
Frequency Range: 10 Hz to 1 kHz (ISO 2954 compliant)
Velocity Range: 0.5 to 199.9 mm/s
Acceleration Range: 0.5 to 199.9 m/s²
Displacement Range: 0.005 to 1.999 mm
Accuracy: ±(5% + 2 digits)
Data Logging: Real-time SD Card (1GB to 16GB capacity)
Sampling Time: Auto (1 to 3600 seconds) or Manual
Display: LCD with green backlight
Data Output: RS232 / USB PC interface
Operating Temperature: 0 to 50 °C
Operating Humidity: Maximum 85% R.H.
Power Supply: 6 x 1.5V AA batteries or 9V DC adapter
Meter Dimensions: 203 x 76 x 38 mm
Probe Dimensions: Ø 16 mm x 37 mm
Meter Weight: 515 g
Probe Weight: 99 g

Procurement Information:
Lead Time: Subject to global inventory availability and regional logistics
Condition: Factory new, calibrated testing equipment

Key Attributes
Type: Vibration Meter
Accuracy: 2%
Place of origin: China
Customized support: Software Reengineering
Power: 0.5 to 199.9 mm/s
Protection Class: IP65
Voltage: Other
Brand name: Lutron
Application: Vibration Meter
Warranty: 1 years
Power Supply: 6 x AA Batteries or 9V Adapter
Velocity range: 0.5 to 199.9 mm/s
Interface: RS232/USB
Frequency range: 10 Hz - 1 kHz
Data logging: SD Card

Packaging and Delivery
Selling Units: Single item
Single package size: 38X35X19 cm
Single gross weight: 2.000 kg
