Description
The Mitutoyo 543-701 is a high-precision Absolute Digimatic Indicator belonging to the ID-C series, engineered for rigorous dimensional inspection and quality control applications. Utilizing Mitutoyo’s Original Engineering in electrostatic capacitance linear encoders, this digital indicator ensures absolute position tracking, eliminating the need for zero-setting upon power-on and preventing over-speed errors during dynamic measurements.
Technical Specifications:
Model Number: 543-701
Product Type: Absolute Digimatic Indicator (ID-C Series)
Measurement Range: 0 – 0.5 inch (0 – 12.7 mm)
Resolution: 0.0005 inch / 0.01 mm
Accuracy: ±0.0008 inch
Measuring Force: 1.5 N or less
Stem Diameter: 3/8 inch (ANSI/AGD Standard)
Contact Point Thread: #4-48 UNF
Display: Large LCD with 330° rotation
Power Supply: SR44 Silver Oxide Button Cell (938882)
Battery Life: Approx. 7,000 hours of continuous use
Data Output: SPC (Digimatic) compatible
Operating Temperature: 0°C to 40°C
Weight: 170 g
Technical Compatibility and Integration:
The 543-701 indicator features SPC data output, allowing seamless integration into statistical process control networks and automated inspection rigs. It offers GO/±NG tolerance judgment, displaying results directly on the high-contrast LCD. The 330° rotating face ensures optimal readability from multiple angles when mounted on custom fixtures or standard magnetic bases. Technical Compatibility is guaranteed with all standard Mitutoyo Digimatic cables, multiplexers, and data loggers.
Industrial Application:
This precision instrument is critical for aerospace component verification and automotive powertrain manufacturing, where exact inch-based dimensional tolerances are mandatory. Its robust ABSOLUTE encoder design excels in high-throughput machining environments, providing reliable runout, flatness, and depth measurements without signal degradation.
Procurement and Lead Time:
Available for immediate global dispatch. Standard Lead Time applies based on regional distribution hubs. Supplied with factory inspection certificate and user documentation to support stringent quality management systems.
Key Attributes
Accuracy: 0.003 mm
Material: Plastic+Iron
Place of origin: Japan
Model number: 543-701
Brand name: Mitutoyo
Customized support: OEM, ODM
Warranty: 1 years
Range: 0.5"/12.7 mm
Digital Step: 0.00005"/0.001 mm
Hysteresis: 0.0001"/0.002 mm
Max. Response Speed: Unlimited
Power Supply: 1 battery SR-44
Packaging and Delivery
Selling Units: Single item
Single package size: 26X18X13 cm
Single gross weight: 1.500 kg
