Description
The UNI-T UT309C and UT309E Professional Infrared Thermometers are engineered for rigorous industrial environments requiring non-contact temperature diagnostics with high precision. Built with Original Engineering standards, these devices feature a ruggedized housing that withstands a 3-meter drop and carries an IP65 environmental rating, ensuring optimal performance against dust ingress and low-pressure water jets. The dual-laser targeting system provides superior accuracy in pinpointing measurement areas on complex machinery.
Technical Specifications:
Model: UT309C / UT309E
Temperature Range (UT309C): -35°C to 800°C
Temperature Range (UT309E): -35°C to 850°C
Distance to Spot Ratio (D:S): 12:1 (UT309C) / 20:1 (UT309E)
Response Time: < 250ms (95% of reading)
Emissivity: 0.10 to 1.00 (Adjustable)
Spectral Response: 8μm to 14μm
Laser Type: Dual Laser, Class 2 (< 1mW)
Display: High-contrast EBTN LCD
Environmental Protection: IP65
Drop Resistance: 3m
Power Supply: 9V battery (6F22)
Weight: 292g
Dimensions: 189mm x 118mm x 55mm
Certifications: CE, RoHS, EN 61326-1, EN 60825-1
Advanced Features:
High/Low temperature LED and audio alarms for rapid fault detection.
MAX/MIN/AVG/DIF measurement modes for comprehensive thermal profiling.
Data hold and auto power-off functionalities for extended lifecycle value.
Lock measurement capability for continuous temperature monitoring without trigger depression.
Industrial Application:
These infrared thermometers are critical for predictive maintenance in heavy manufacturing, electrical panel inspections, HVAC system diagnostics, and automotive engine troubleshooting. The UT309E’s 20:1 D:S ratio specifically allows technicians to safely measure high-voltage or extreme-heat components from a secure distance. Technical Compatibility is guaranteed across standard industrial maintenance protocols.
Procurement and Customization:
Customizable OEM and ODM services are fully supported to meet specific corporate branding or specialized functional requirements. Standard orders feature an optimized Lead Time to ensure minimal operational downtime for your facility.
Key Attributes
Type: Infrared Thermometer
Place of origin: Guangdong, China
Model number: UT309A UT309C UT309E
Brand name: UNI-T
Customized support: OEM, ODM
Material: Plastics
Warranty: 1 years
Temperature range: -35°C~450°C
Accuracy: ±1.8%
D:S ratio: 10:1
Emissivity: 0.95
Laser type: Class 2
Laser wavelength: 630nm~670nm
Power: 9V battery (6F22)
Display: 32mm x 29mm
Theory: Infrared Thermometer
Packaging and Delivery
Selling Units: Single item
Single package size: 28X21X15 cm
Single gross weight: 1.500 kg
