Description
The Megger MIT1525 is a premium 15kV diagnostic insulation resistance tester engineered for the rigorous demands of high-voltage electrical infrastructure. Designed with Original Engineering principles, this digital megohmmeter delivers unparalleled accuracy in assessing the condition of critical assets. The unit features a robust dual-case design, ensuring maximum durability in harsh field environments while maintaining an IP65 rating against dust and moisture ingress when closed. With a rapid Lead Time for critical testing requirements, the MIT1525 ensures seamless Technical Compatibility with standard asset management software through advanced USB and Bluetooth data logging capabilities.
Technical Specifications:
Manufacturer: Megger
Model Number: MIT1525
Equipment Type: Diagnostic Insulation Resistance Tester
Maximum Test Voltage: 15 kV DC
Maximum Resistance Range: 30 TΩ
Short Circuit Current: 3 mA
Diagnostic Test Modes: IR, Timed IR, DAR, PI, DD, SV, Ramp
Safety Rating: CAT IV 1000 V (operable up to 3000 m altitude)
Ingress Protection: IP65 (lid closed)
Operating Temperature: -20°C to +50°C
Power Supply: Li-ion battery (with AC line operation capability)
Display: Advanced LCD with automatic backlight
Dimensions: 315 x 285 x 181 mm
Weight: 7.1 kg
Warranty: 1 Year
Industrial Application and Lifecycle Value:
The MIT1525 is specifically deployed in utility substations, heavy industrial plants, and traction networks for the commissioning and predictive maintenance of high-voltage cables, large rotating machinery, and power transformers. The exceptional 30 TΩ measurement capacity combined with a 3 mA short circuit current allows test engineers to rapidly charge highly capacitive loads and detect microscopic insulation degradation before catastrophic failure occurs. By utilizing advanced diagnostic metrics such as Dielectric Discharge (DD) and Polarization Index (PI), this instrument provides critical lifecycle data, minimizing unplanned downtime and optimizing the operational lifespan of multi-million dollar electrical assets.
Key Attributes
Place of origin: United Kingdom
Customized support: OEM, ODM
Power: 15kV
Brand name: Mer
Warranty: 1 Year
Model number: MIT1525
Product name: Insulation Resistance Tester
Model: MIT1525
Test Voltage Range: 1000 V, 2500 V, 5000 V, 10000 V, 15000 V
Accuracy: +4%
Resistance Range 1: 10 kΩ to 15 TΩ at 5 kV
Resistance Range 2: 10 kΩ to 20 TΩ at 10 kV
Resistance Range 3: 10 kΩ to 30 TΩ at 15 kV
Insulation Test Alarm: 100 kΩ to 10 GΩ
IP Rating: IP65 (lid closed), IP40 (lid open)
Temperature Operating: -4 to 122°F (-20 to 50°C)
Packaging and Delivery
Selling Units: Single item
Single package size: 51X38X35 cm
Single gross weight: 10.600 kg
