Description
Mitutoyo 184-302S Precision Stainless Steel Feeler Gauge.Engineered for high-fidelity clearance and gap measurement, the Mitutoyo 184-302S represents the pinnacle of Original Engineering in dimensional metrology. This 13-leaf thickness gauge provides rigorous accuracy for critical industrial alignments and tolerance verification.
Technical Specifications:
Brand: Mitutoyo
Model: 184-302S
Component Type: Thickness Gap Gauge
Material: Hardened Stainless Steel
Number of Leaves: 13
Measurement Range: 0.05 mm to 1.00 mm
Leaf Configurations: 0.05, 0.10, 0.15, 0.20, 0.25, 0.30, 0.40, 0.50, 0.60, 0.70, 0.80, 0.90, 1.00 mm
Leaf Length: 150 mm
Accuracy (0.05 – 0.15 mm): ±0.005 mm
Accuracy (0.20 – 0.50 mm): ±0.012 mm
Accuracy (0.60 – 1.00 mm): ±0.020 mm
Weight: 0.12 kg
Calibration Temperature: 20 °C
Locking Mechanism: Knurled thumb nut
Industrial Application:
Designed for environments requiring absolute Technical Compatibility and strict dimensional control. The 184-302S is critical for automotive valve clearance adjustments, aerospace turbine blade gap inspections, and precision CNC spindle alignment. The high-carbon stainless steel construction ensures superior corrosion resistance and dimensional stability in harsh manufacturing environments, significantly extending the operational lifecycle.
Procurement and Lifecycle:
Standardized manufacturing ensures a highly predictable Lead Time for global B2B procurement, supporting uninterrupted quality assurance and maintenance operations.
Key Attributes
Place of origin: Japan
Model number: 184-302S
Brand name: Mitutoyo
Customized support: OEM, ODM
Warranty: 1 years
Product name: Mitutoyo
Model: 184-302S
Inch-Metric: Metric
Range: 0,03-0,1 mm by 0,01 mm, 0,2-0,5 mm by 0,1 mm, 0,15 mm
Accuracy: 0,03-0,15 mm: ±0,005 mm, 0,2- 0,5 mm: ±0,012 mm, 0,55-1 mm: ±0,02 mm
Number of leaves: 13
Leaf length: 150 mm
Packaging and Delivery
Selling Units: Single item
Single package size: 20X12X9 cm
Single gross weight: 1.000 kg
