$4.00

SKU: 710746764591 Brand:

Description

Manufacturer: Delta Electronics
Model Number: AFB0912VH
Product Category: High-Performance Axial Cooling Fan

Technical Specifications:
Frame Size: 92mm x 92mm x 25.4mm (9225)
Rated Voltage: 12V DC
Operating Voltage Range: 7.0V DC to 13.8V DC
Rated Current: 0.60A
Input Power: 7.20W
Rated Speed: 3800 RPM
Maximum Airflow: 67.80 CFM (1.920 m³/min)
Maximum Static Pressure: 7.67 mmH2O (0.302 inH2O)
Noise Level: 45.0 dB(A)
Bearing Type: Dual Ball Bearing System
Termination: 3-Wire Lead (Red/Black/Blue) with Tachometer Output
Weight: 120g

Material and Construction:
Impeller Material: Plastic (UL 94V-0)
Frame Material: Plastic (UL 94V-0)
Motor Type: Brushless DC Motor
Insulation Class: Class A
Expected Life: 70,000 Hours at 40°C / 65% RH

Environmental and Safety Standards:
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +75°C
Certifications: UL, CSA, VDE, CE, RoHS Compliant
Protection: Locked Rotor Protection, Polarity Protection

Industrial Application and Technical Compatibility:
The Delta AFB0912VH is engineered for high-density thermal management in server enclosures, industrial power supplies, and telecommunications infrastructure. Its dual ball bearing architecture ensures long-term reliability in continuous 24/7 duty cycles. This component is a critical replacement part for Original Engineering specifications requiring high static pressure to overcome airflow resistance in compact heat sinks or densely packed PCB arrays.

Inventory and Logistics:
Condition: New Original
Lead Time: Immediate Dispatch Available
Technical Compatibility: Direct replacement for standard 92mm 12V DC cooling systems.

New AFB0912VH Delta Fan 9225/12V 0

New AFB0912VH Delta Fan 9225/12V 0

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
