$9.00

SKU: 924143649002 Brand: ,

Description

Manufacturer: NMB-MinebeaMitsumi
Model Number: 09225VE-24P-CA
Product Category: DC Axial Cooling Fan
Frame Dimensions: 92 mm x 92 mm x 25 mm
Rated Voltage: 24 V DC
Operating Voltage Range: 14.0 V DC to 27.6 V DC
Rated Current: 0.37 A
Power Consumption: 8.88 W
Bearing Architecture: Dual Precision Ball Bearings
Nominal Speed: 4200 RPM ± 10%
Air Flow Volume: 2.15 m³/min (76.0 CFM)
Static Pressure: 95.0 Pa
Acoustic Noise Rating: 46.5 dBA
Frame Material: Glass-Fiber Reinforced PBT (UL94V-0)
Impeller Material: Glass-Fiber Reinforced PBT (UL94V-0)
Interface Type: 2-Wire Dedicated Waterproof Connector Harness
Motor Protection: Reverse Polarity Protection, Locked Rotor Auto-Restart
Insulation Resistance: 10 MΩ minimum at 500 V DC
Dielectric Withstanding: 500 V AC for 1 minute
Operating Temperature Range: -10 °C to +70 °C
Storage Temperature Range: -40 °C to +80 °C
Life Expectancy (L10): 70,000 Hours at 40 °C
Weight: 140 g

SYSTEM ARCHITECTURE & TECHNICAL COMPATIBILITY
This unit is engineered specifically for enclosed power electronics and automation cabinets requiring sustained high-pressure airflow. Technical Compatibility includes direct integration as the primary cooling exhaust/intake unit for Yaskawa Motoman YRC1000 robot control cabinets, modular servo drives, and variable frequency inverters. The specialized waterproof connector and conformal insulation prevent component failure caused by airborne particulates, coolant mist, and ambient industrial contaminants.

CRITICAL APPLICATION ROLE
In continuous manufacturing environments, robotic power modules and IGBT switching components generate intense localized heat within the YRC1000 enclosure. The 09225VE-24P-CA maintains stable thermal dissipation across high-density circuit arrays, preventing thermal throttling, erratic sensor feedback, and catastrophic drive over-temperature faults.

SUPPLY CHAIN & LOGISTICS
Condition: 100% Original Engineering standard, brand new factory stock
Packaging: Factory-sealed individual moisture-barrier and anti-static packaging
Lead Time: Standard stock ready for immediate global dispatch to minimize industrial line stoppage

NMB 09225VE-24P-CA fan

NMB 09225VE-24P-CA fan

NMB 09225VE-24P-CA fan

NMB 09225VE-24P-CA fan

NMB 09225VE-24P-CA fan

NMB 09225VE-24P-CA fan

NMB 09225VE-24P-CA fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
