$6.43

SKU: 702608078686 Brand:

Description

The SUNON PF80251B1-000C-A99 is a high-performance, industrial-grade DC axial cooling fan engineered for continuous operation in demanding thermal management environments. Utilizing high-efficiency DC motor technology combined with a precision dual ball bearing system, this 80x80x25mm chassis fan delivers exceptional volumetric airflow and static pressure. It is specifically designed to mitigate thermal bottlenecks in densely packed electronic enclosures.

Technical Specifications
Manufacturer: SUNON
Model Number: PF80251B1-000C-A99
Dimensions: 80 x 80 x 25 mm
Rated Voltage: 12 VDC
Operating Voltage Range: 6.0 to 13.8 VDC
Starting Voltage: 6.0 VDC
Rated Current: 0.34 A
Power Consumption: 4.1 W
Rotational Speed: 4800 RPM ± 10%
Maximum Airflow: 60.0 CFM (1.7 m³/min)
Static Pressure: 0.41 in-H2O
Acoustic Noise: 46.0 dB(A)
Bearing Type: Precision Dual Ball Bearing
Frame Material: Thermoplastic PBT (UL94V-0)
Impeller Material: Thermoplastic PBT (UL94V-0)
Operating Temperature: -10°C to +70°C
Life Expectancy: 70,000 hours at 40°C
Weight: 91 g
Termination: Wire Leads

Engineering and Integration
This component represents the pinnacle of Original Engineering, ensuring exact Technical Compatibility with existing 12V DC thermal management architectures. The dual ball bearing configuration minimizes rotational friction, thereby extending the operational lifecycle even under high-temperature fluctuations. The UL94V-0 rated thermoplastic construction provides critical flame retardance for industrial safety compliance.

Industrial Applications
The high-air volume characteristics of the PF80251B1-000C-A99 make it strictly suited for high-density server chassis, telecommunications cabinets, automated industrial control panels, and power supply cooling. By maintaining optimal operating temperatures, this fan prevents thermal throttling in mission-critical microprocessors and power conversion components.

Procurement and Lifecycle
We ensure an optimized Lead Time for this exact specification, minimizing downtime for critical infrastructure maintenance. As a direct replacement or OEM integration part, it guarantees sustained thermal performance and system reliability.

PF80251B1-000C-A99 New Original SUNON fan

PF80251B1-000C-A99 New Original SUNON fan

PF80251B1-000C-A99 New Original SUNON fan

PF80251B1-000C-A99 New Original SUNON fan

PF80251B1-000C-A99 New Original SUNON fan

PF80251B1-000C-A99 New Original SUNON fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
