Description
The Testo 104-IR (Part Number 0560 1040) is a highly precise, dual-purpose temperature measurement instrument engineered for rigorous industrial and commercial food safety applications. Combining a high-performance infrared sensor for rapid surface scanning with a robust NTC penetration probe for core temperature verification, this unit ensures comprehensive thermal profiling. Designed with a rugged, IP65-rated folding mechanism, it delivers immediate, reliable data critical for HACCP compliance and quality assurance in demanding environments.
Technical Specifications
Part Number: 0560 1040
Model: 104-IR
Measurement Technology: Infrared (IR) and NTC Thermistor
NTC Measuring Range: -50 °C to +250 °C
NTC Accuracy: ±0.5 °C (-30.0 to +99.9 °C)
NTC Resolution: 0.1 °C
IR Measuring Range: -30 °C to +250 °C
IR Accuracy: ±1.5 °C or ±1.5% of measured value (0.0 to +250.0 °C)
IR Resolution: 0.1 °C
Distance to Spot Ratio (Optics): 10:1
Laser Sighting: 2-point laser
Emissivity: Adjustable from 0.10 to 1.00
Protection Class: IP65 (Dust-tight and protected against water jets)
Housing Material: ABS / TPE / PC, die-cast zinc, stainless steel probe
Probe Dimensions: Length 106 mm, Tip Ø 3 mm
Dimensions (Folded): 162 x 48 x 19 mm
Weight: 197 g
Battery Type: 2 x AAA
Battery Life: Approximately 10 hours
Certifications: EN 13485, HACCP International
Industrial Application and Integration
The Testo 104-IR is purpose-built for the food processing sector, cold chain logistics, and high-volume retail environments where rapid, non-destructive surface temperature checks must be immediately validated by core temperature readings. In a meat processing facility, operators utilize the 10:1 IR optics to scan incoming pallets for temperature deviations without compromising packaging integrity. If a surface anomaly is detected, the folding NTC probe is deployed to verify internal product temperatures, ensuring strict adherence to safety thresholds.
Procurement and Lifecycle Value
Sourced through Original Engineering channels, the Testo 104-IR guarantees maximum Technical Compatibility with existing HACCP digital logging frameworks. Its durable ABS/TPE housing and IP65 rating allow for aggressive washdown procedures, extending the operational lifecycle of the instrument. Standard Lead Time for this component is optimized for rapid deployment to minimize downtime in critical quality control operations.
Key Attributes
Type: Infrared Thermometer
Place of origin: China
Model number: 104-IR
Brand name: Testo
Infrared resolution: Other
Material: Plastic
Warranty: 1 years
Product name: Testo infrared thermometer
Model: 104-IR
Measuring Range: -58 to 482°F (-50 to 250°C)
Accuracy: ±1 %
Temperature - Infrared Measuring range: -22° to 482 °F / -30 to +250 °C
Measuring rate: 0.5 sec
Protection class: IP65
Display type: LCD
Measurement value: Temperature °C / °F / °R
Weight: 197 g
Packaging and Delivery
Selling Units: Single item
Single package size: 29X18X12 cm
Single gross weight: 0.500 kg
