$14.29

SKU: 953459160690 Brand:

Description

The FULLTECH UF-12A23 BTH is an industrial-grade AC axial cooling fan engineered for high-reliability thermal management in electrical enclosures and control cabinets. Manufactured by Taiwan Fuyou, this compact yet powerful unit utilizes a robust die-cast aluminum housing to withstand harsh industrial environments while maintaining optimal heat dissipation.

Technical Specifications
Manufacturer: FULLTECH (Taiwan Fuyou)
Model Number: UF-12A23 BTH
Fan Type: AC Axial Cooling Fan
Dimensions: 120 x 120 x 38 mm
Operating Voltage: 115V AC
Frequency: 50/60 Hz
Power Consumption: 14W / 12W
Bearing System: Precision Dual Ball Bearing
Housing Material: Black Die-Cast Aluminum
Impeller Material: Thermoplastic PBT (UL94V-0)
Connection Type: Terminal (Insert Interface)
Operating Temperature: -40°C to +70°C
Airflow: ± 2.5 to 3.0 m³/min
Weight: 0.53 kg
Mounting Hole Diameter: Ø 4.3 mm

Industrial Application
This cooling fan is specifically designed for forced-air convection in high-density electrical boxes, CNC control cabinets, and industrial power supply racks. The dual ball bearing architecture ensures continuous, low-friction operation in environments susceptible to mechanical vibration and elevated ambient temperatures. By preventing thermal throttling in variable frequency drives (VFDs) and programmable logic controllers (PLCs), it directly extends the operational lifespan of critical automation hardware.

Procurement & Lifecycle Value
Original Engineering: 100% authentic FULLTECH component ensuring exact drop-in replacement and factory-certified performance.
Technical Compatibility: The standardized 120x120x38mm form factor and quick-connect terminal interface guarantee seamless integration with existing cabinet cutouts and wiring harnesses.
Lead Time: Ready for immediate dispatch with same-day inspection and shipping support to minimize facility downtime.

UF-12A23 BTH FULLTECH fan

UF-12A23 BTH FULLTECH fan

UF-12A23 BTH FULLTECH fan

UF-12A23 BTH FULLTECH fan

UF-12A23 BTH FULLTECH fan

UF-12A23 BTH FULLTECH fan

UF-12A23 BTH FULLTECH fan

UF-12A23 BTH FULLTECH fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
