US12D23 STYLE FAN 230V fan

Name: US12D23 STYLE FAN 230V fan
SKU: 892393634576
Availability: InStock
Rating: 5 (4 reviews)

$18.57

SKU: 892393634576

Description
Reviews (0)

Description

The US12D23 is an industrial-grade AC axial compact fan engineered for continuous thermal management in high-impedance electrical enclosures, industrial automation cabinets, and precision processing machinery. Developed under Japanese precision standards, this unit provides reliable forced-air cooling through Original Engineering tolerances, minimizing MTBF degradation under continuous duty cycles.

TECHNICAL SPECIFICATIONS
Manufacturer Series: US Axial Fan Series
Model Number: US12D23
Rated Voltage: 230 VAC
Operating Voltage Range: 198 VAC – 253 VAC
Rated Frequency: 50/60 Hz
Rated Power Consumption: 16 W (50 Hz) / 15 W (60 Hz)
Rated Current: 0.08 A (50 Hz) / 0.07 A (60 Hz)
Nominal Speed: 2600 RPM (50 Hz) / 2900 RPM (60 Hz)
Max Airflow: 2.55 m³/min (90 CFM) at 50 Hz / 2.97 m³/min (105 CFM) at 60 Hz
Max Static Pressure: 58.8 Pa (50 Hz) / 73.5 Pa (60 Hz)
Acoustic Noise Level: 39 dB(A) (50 Hz) / 43 dB(A) (60 Hz)
Motor Topology: Single-Phase Shaded Pole AC Induction Motor
Motor Protection: Impedance Protected
Bearing Mechanism: Dual Precision Ball Bearings
Frame Construction: Die-Cast Aluminum with Anti-Corrosion Finish
Impeller Construction: Glass-Fiber Reinforced PBT (UL94V-0 Flammability Rated)
Dimensions: 120 mm x 120 mm x 38 mm (±0.5 mm)
Mounting Hole Pitch: 104.8 mm x 104.8 mm
Mounting Hole Diameter: Ø 4.3 mm (4 Holes)
Dielectric Strength: 1500 VAC for 1 minute
Insulation Resistance: Minimum 100 MΩ at 500 VDC
Operating Temperature Range: -10 °C to +70 °C
Storage Temperature Range: -30 °C to +85 °C
Expected Service Life: 50,000 Hours (at 40 °C, L10 specification)
Termination Type: Faston Terminal / Solder Lug Configuration
Weight: 520 g

APPLICATION & THERMAL LOGIC
In enclosed motor drive cabinets (VFDs), power distribution switchgear, and CNC numerical control consoles, localized heat flux frequently causes localized thermal throttling and component failure. The US12D23 delivers a high static-to-airflow ratio across dynamic thermal loads, effectively clearing air resistance caused by dense air filters and compact component layouts. Its dual ball-bearing architecture ensures mechanical stability across vertical and horizontal mounting axes without lubrication migration.

INTEGRATION & PROCUREMENT
Technical Compatibility: Fits global standardized 120 x 120 x 38 mm fan cutouts; direct replacement for legacy Japanese 230V AC frame assemblies.
Condition: Surplus New / Unused OEM inventory.
Lead Time: Immediate dispatch available for MRO retrofits and urgent line replenishment.

US12D23 STYLE FAN 230V fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
