Description

The 09225SS-24N-AL is an industrial-grade DC axial cooling fan engineered for thermal management in heavy-duty electronic enclosures, specifically serving as a direct replacement component for Schneider electric inverters. Featuring a 3-wire configuration with an integrated fault alarm circuit, this 92mm fan ensures active system monitoring to prevent critical overheating in variable frequency drives (VFDs) and motor control centers.

Technical Specifications:
Model: 09225SS-24N-AL
Component Type: DC Axial Cooling Fan
Nominal Voltage: 24V DC
Operating Voltage Range: 14.0V to 27.6V DC
Dimensions: 92mm x 92mm x 25mm
Wiring Configuration: 3-Wire
Sensor Type: Fault Alarm / Locked Rotor Output (AL)
Bearing System: Precision Ball Bearing
Rated Speed: 2800 RPM ± 10%
Maximum Airflow: 1.35 m³/min
Acoustic Noise: 32.0 dB(A)
Housing Material: Thermoplastic UL94V-0
Impeller Material: Thermoplastic UL94V-0
Operating Temperature: -10°C to +70°C
Weight: 95g

Application and Lifecycle Value:
Technical Compatibility: Designed for seamless integration into Schneider variable frequency drives and industrial inverters. The 3-wire fault alarm provides real-time feedback to the drive logic controller, triggering automated shutdown protocols if fan failure is detected, thereby protecting expensive IGBT components.
Original Engineering: Manufactured to exact OEM specifications, ensuring precise airflow impedance matching and thermal compliance with Schneider equipment.
Lead Time: Optimized inventory processing ensures minimal lead time, allowing facilities to rapidly restore drive functionality and avoid prolonged production halts.
