$21.43

SKU: 906188582115 Brand:

Description

SANYO DENKI SAN ACE 120 – HIGH STATIC PRESSURE DC AXIAL FAN
Model: 9HV1248P1G013
Manufacturer: Sanyo Denki Co., Ltd.
Series: San Ace 120 (9HV Type)

MODEL DECODING & ARCHITECTURE
9HV: High Static Pressure Series
12: Frame Size 120 mm x 120 mm
48: Rated Voltage 48 V DC
P: PWM Speed Control and Pulse Sensor (Tachometer Output)
1: High-Speed Tier Specification
G: Frame Structural Code
013: Lead Wire and Internal Circuit Specification

TECHNICAL SPECIFICATIONS
Frame Dimensions: 120 mm x 120 mm x 38 mm
Frame Material: Aluminum Die-Cast / Reinforced Resin
Impeller Material: Glass-Fiber Reinforced Plastic (UL 94V-0)
Bearing System: Dual Precision Ball Bearings
Rated Voltage: 48 V DC
Operating Voltage Range: 36.0 V DC to 72.0 V DC
Rated Current: 2.00 A
Rated Input Power: 96.0 W
Rated Rotational Speed: 10,500 RPM
Maximum Airflow: 8.50 m³/min (300 CFM)
Maximum Static Pressure: 1,350 Pa (5.42 inchH2O)
Sound Pressure Level: 71.0 dB(A)
Expected Operating Life: 40,000 Hours at 60 °C (70,000 Hours at 40 °C)
Operating Temperature Range: -20 °C to +70 °C
Storage Temperature Range: -30 °C to +70 °C
Termination: 4-Wire Lead (V+, GND, PWM Control Input, Tachometer Output)
Weight: 490 g
Dielectric Strength: 50/60 Hz, 500 V AC, 1 Minute (Between Lead Wire and Frame)
Insulation Resistance: 10 MΩ or Greater at 500 V DC
Certifications: UL Recognized (UL507), CSA, TÜV, CE, RoHS Compliant

INDUSTRIAL APPLICATION & THERMAL INTEGRATION
The San Ace 9HV1248P1G013 delivers extreme static pressure designed specifically for dense thermal enclosures where standard axial fans experience airflow stalling. Engineered for 48 V telecom rectifiers, 1U/2U high-density server chassis, optical transport network nodes, centralized industrial UPS enclosures, and rapid-cooling battery storage racks. Its steep P-Q curve maintains critical CFM throughput across heavily packed heatsinks, backplanes, and restrictive ducting.

PROCUREMENT & COMPLIANCE
Original Engineering: Genuine Sanyo Denki high-reliability motor and aerodynamic blade geometry.
Technical Compatibility: Standard 120 mm mounting footprint with 4-wire PWM duty-cycle speed regulation and tachometer feedback for closed-loop thermal control.
Lead Time: In-stock units ready for immediate dispatch; standard factory lead time applies for volume project allocations.

9HV1248P1G013 Sanyo SanAce120 fan

9HV1248P1G013 Sanyo SanAce120 fan

9HV1248P1G013 Sanyo SanAce120 fan

9HV1248P1G013 Sanyo SanAce120 fan

9HV1248P1G013 Sanyo SanAce120 fan

9HV1248P1G013 Sanyo SanAce120 fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
