AG12024xB257100 ADDA 12025/24V fan
AG12024xB257100 ADDA 12025/24V fan

AG12024xB257100 ADDA 12025/24V fan

$5.57

SKU: 681268155090 Brand:

Description

The ADDA AG12024XB257100 is a high-performance DC axial flow cooling fan engineered for severe industrial environments. Designed with Original Engineering standards, this component delivers exceptional volumetric airflow to prevent thermal throttling in high-load electrical systems. Utilizing a premium dual ball bearing architecture, it ensures extended lifecycle reliability and continuous operation under demanding thermal conditions. With optimized Lead Time availability, this fan provides immediate Technical Compatibility for critical infrastructure upgrades and maintenance.

TECHNICAL SPECIFICATIONS
Manufacturer: ADDA Corporation
Model Number: AG12024XB257100
Fan Type: DC Axial Flow
Dimensions: 120 mm x 120 mm x 25 mm
Mounting Hole: Ø 4.3 ± 0.2 mm
Rated Voltage: 24V DC
Operating Voltage Range: 14.0V to 27.6V DC
Rated Current: 0.46 A
Power Consumption: 11.04 W
Bearing System: Dual Ball Bearing
Speed Category: Extra High Speed
Volumetric Airflow: 3.11 m³/min
Acoustic Noise: 47 dB(A)
Housing Material: UL94V-0 Glass Filled Polyester (PBT)
Impeller Material: UL94V-0 Glass Filled Polyester (PBT)
Operating Temperature: -10°C to +70°C
Weight: 156 g
Connection: Wire Leads
Compliance: CE, RoHS, UL

INDUSTRIAL APPLICATION
This high-velocity cooling fan is specifically engineered for integration into heavy-duty welding machines and industrial frequency converters (VFDs). In continuous arc welding applications, internal components generate rapid, concentrated heat. The AG12024XB257100 provides the necessary static pressure and large air volume to aggressively dissipate thermal buildup across heat sinks and insulated gate bipolar transistors (IGBTs). Its dual ball bearing design resists the ingress of metallic dust and particulate matter common in fabrication facilities, ensuring stable frequency converter operation and preventing catastrophic thermal failure during continuous production cycles.

AG12024xB257100 ADDA 12025/24V fan

AG12024xB257100 ADDA 12025/24V fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
