Description

The Nidec D1751S24B6CZ-16 is a premium-grade, high-velocity DC axial cooling fan engineered for demanding industrial environments. Recognized for its exceptional airflow capacity, this 24V inverter fan is designed to provide critical thermal management for high-density electronic enclosures, variable frequency drives (VFDs), and heavy-duty automation systems.

Technical Specifications:
Manufacturer: Nidec
Model Number: D1751S24B6CZ-16
Equipment Type: High-Velocity DC Axial Fan
Dimensions: Ø 172mm x 51mm (17251 Form Factor)
Rated Voltage: 24V DC
Operating Voltage Range: 18.0V to 27.6V DC
Input Current: 2.20A
Power Consumption: 52.8W
Bearing System: High-Precision Dual Ball Bearing
Maximum Airflow: 300 CFM (8.5 m³/min)
Acoustic Noise Level: 65 dBA
Frame Material: Die-cast Aluminum Alloy
Impeller Material: Thermoplastic PBT (UL94V-0)
Operating Temperature: -10°C to +70°C
Weight: 0.85 kg
Termination: Multi-wire Lead with Sensor Output

Original Engineering & Lifecycle Value:
Manufactured with Nidec proprietary brushless DC motor technology, the D1751S24B6CZ-16 guarantees extended operational longevity and minimal maintenance. The dual ball bearing architecture ensures high rotational stability under continuous 24/7 operation. This authentic component ensures exact Technical Compatibility with OEM inverter systems, preventing thermal throttling and protecting sensitive circuitry. Optimized Lead Time protocols are strictly maintained for this component, ensuring your facility achieves rapid integration and optimal uptime.

Industrial Applications:
This high-performance cooling module is specifically deployed in scenarios requiring rapid heat dissipation against high static pressure. It is critical for maintaining safe operating temperatures in industrial motor drives, solar power inverters, telecommunications base stations, CNC machinery cabinets, and large-scale power supply units.

D1751S24B6CZ-16 Nidec Fan

D1751S24B6CZ-16 Nidec Fan

D1751S24B6CZ-16 Nidec Fan

D1751S24B6CZ-16 Nidec Fan

D1751S24B6CZ-16 Nidec Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
