Enerpac RSM-200 Flat-Jac Low Height Hydraulic Cylinder
TECHNICAL PROFILE & MODEL DECODING
Model Series: RSM Series (Flat-Jac Single-Acting Low Height Cylinder)
Model Number: RSM-200
Actuation Type: Single-Acting, Heavy-Duty Spring Return
Nominal Capacity: 20 Ton (201 kN)
Stroke Length: 11 mm
Maximum Operating Pressure: 700 bar (10,000 psi)
Cylinder Effective Area: 28.7 cm²
Oil Capacity: 32 cm³
Collapsed Height: 51 mm
Extended Height: 62 mm
Plunger Diameter: 50.8 mm
Cylinder Bore Diameter: 60.5 mm
Fluid Compatibility: ISO VG 32 / ISO VG 46 Hydraulic Mineral Oil
Port Type: 3/8 inch-18 NPTF with CR-400 High-Flow Coupler
Body Construction: Forged High-Strength Alloy Steel
Plunger Coating: Hard Chrome Plated
External Coating: Baked Enamel Corrosion-Resistant Finish
Base Mounting: Dual Pre-Drilled Fixturing Holes
Operating Temperature Range: -20 °C to +70 °C
Weight: 3.1 kg
SYSTEM INTEGRATION & TECHNICAL COMPATIBILITY
The RSM-200 is engineered for high-pressure hydraulic circuits operating up to 700 bar (10,000 psi). Direct technical compatibility is established with standard 700-bar manual hand pumps (such as Enerpac P-392 / P-80), air-over-hydraulic units (PATG-1102N), and electric power units (ZU4 / ZE-Series). The unit integrates a standard CR-400 coupler compatible with the complete CH-604/CR-400 quick-connect series. Built-in base mounting holes permit rigid fixturing into custom presses, spreaders, and automated assembly fixtures.
CRITICAL APPLICATION SCENARIOS
The ultra-low collapsed profile (51 mm) combined with a 20-ton lifting capacity solves clearance constraints in structural and heavy industrial maintenance environments. Primary operational deployments include:
– Bridge bearing maintenance, replacement, and structural jacking where overhead envelope clearance is below 60 mm.
– Heavy machinery leveling, turbine foot shimming, and prime mover alignment.
– Flange separation and heavy weldment positioning in shipyards, petrochemical plants, and structural fabrication.
– High-tonnage pre-stressing and load testing in restricted industrial tooling spaces.
ORIGINAL ENGINEERING & PROCUREMENT DATA
– Production Standard: Original Engineering certified by Enerpac manufacturing protocols.
– Factory Pre-Testing: Proof-tested at 125% rated maximum operating pressure.
– Lead Time: Standard catalog dispatch or expedited logistics based on facility inventory.
Key Attributes
Type: Power hydraulic cylinder
Accuracy: 1%
Place of origin: United States
Customized support: Software Reengineering
Power: 10,000psi
Protection Class: IP65
Voltage: Other
Brand name: ENERPAC
Warranty: 1 years
Maximum Operating Pressure (psi): 10,000
Capacity Class (tonnage): 20
Maximum Cylinder Capacity Advance: 22.1
Return Type: Single-Acting, Spring Return
Plunger Type: Solid
Power: Electronic
Packaging and Delivery
Selling Units: Single item
Single package size: 35X32X21 cm
Single gross weight: 3.000 kg
