Description
The FLIR ONE PRO for Apple iOS systems is a professional-grade, pocket-sized thermal imaging camera engineered to transform standard iOS devices into advanced industrial diagnostic tools. Utilizing FLIR’s Original Engineering, this module integrates a high-resolution Lepton thermal microcamera with proprietary MSX (Multi-Spectral Dynamic Imaging) and VividIR video signal processing. This combination delivers unprecedented thermal clarity by embossing high-fidelity visual details onto the raw thermal feed. Designed for seamless Technical Compatibility with Apple smartphones and tablets via the adjustable OneFit Lightning connector, the FLIR ONE PRO enables rapid, non-destructive field inspections without the need for bulky standalone equipment.
Industrial Application
This thermal imaging module is specifically optimized for electrical panel diagnostics, HVAC system troubleshooting, and mechanical friction analysis in confined spaces. In a high-voltage switchgear inspection scenario, technicians can safely identify phase imbalances, loose connections, or overloaded circuits from a safe distance. The extended temperature measurement range up to 400°C ensures accurate thermal profiling of industrial bearings, motors, and exhaust systems, allowing maintenance teams to detect anomalies before catastrophic failure occurs, thereby minimizing facility downtime.
Technical Specifications
Brand: Teledyne FLIR
Model: FLIR ONE PRO (Apple iOS Edition)
Connector Type: Apple Lightning (OneFit adjustable up to 4 mm)
Thermal Resolution: 160 x 120 pixels (19,200 pixels)
Visual Camera Resolution: 1440 x 1080 pixels
Thermal Sensitivity (NETD): 70 mK
Object Temperature Range: -20°C to 400°C
Accuracy: ±3°C or ±5% of reading
Field of View (FOV): 55° x 43° (±1°)
Frame Rate: 8.7 Hz
Image Enhancement: MSX and VividIR technology
Focus: Fixed 15 cm to infinity
Drop Protection: 1.8 meters
Operating Temperature: 0°C to 35°C
Battery Life: Approximately 1 hour (internal lithium-ion)
Charging Interface: USB-C (female, 5V/1A)
Dimensions: 68 mm x 34 mm x 14 mm
Weight: 36.5 g
Certifications: RoHS, CE, FCC, CEC-BC, EN61236-1
Procurement and Availability
To support critical maintenance schedules, we ensure optimized Lead Time for all FLIR diagnostic instruments. This unit is supplied with full manufacturer documentation to guarantee authentic industrial performance and compliance with global safety standards.
Key Attributes
Place of Origin: China
Model Number: ONE PRO
Brand Name: FLIR
Thermal resolution: 160x120
Visual resolution: 1440x1080
Scene dynamic range: -20°C to 400°C, -4°F - 752°F
Accuracy: ±3°C or ±5%
Packaging and Delivery
Selling Units: Single item
Single package size: 20X20X13 cm
Single gross weight: 1.000 kg
