Description
The Fluke 190-204-III-S is a high-performance, portable ScopeMeter designed for demanding industrial environments. As a Series III instrument, it combines the ruggedness of a multimeter with the advanced diagnostic capabilities of a bench oscilloscope. Engineered for field troubleshooting, this 4-channel device provides electrically isolated inputs, ensuring maximum safety and signal integrity when measuring complex control systems. The -S designation indicates the inclusion of the comprehensive SCC290 kit, featuring FlukeView software and a hard protective case for immediate field deployment and data analysis.
Technical Specifications:
Bandwidth: 200 MHz
Number of Channels: 4 isolated inputs
Real-Time Sample Rate: 2.5 GS/s
Record Length: 10,000 samples per channel
Safety Rating: CAT III 1000 V / CAT IV 600 V
Display Type: High-resolution color LCD
Battery Life: Up to 7 hours (Li-ion)
Environmental Protection: IP51
Operating Temperature: 0 °C to 40 °C
Weight: 2.2 kg
Dimensions: 270 mm x 190 mm x 70 mm
Timebase Accuracy: ± 0.01%
Triggering: Connect-and-View, Free Run, Single Shot, Edge, Delay, Video
Included Software: FlukeView ScopeMeter
Industrial Application:
This portable oscilloscope is critical for troubleshooting three-phase power electronics, variable frequency motor drives (VFDs), and complex industrial control networks. The 4-channel architecture allows technicians to simultaneously inspect input, output, feedback loops, and safety interlocks to diagnose timing issues, transients, and signal amplitude variations. Its CAT IV 600 V rating ensures safe operation directly at the service entrance or on high-energy industrial machinery.
Procurement and Lifecycle Value:
Maintaining Technical Compatibility across your diagnostic fleet is essential for standardized maintenance protocols. This unit represents Fluke Original Engineering, guaranteeing precise calibration and long-term reliability in harsh environments. Contact our procurement team to verify current Lead Time and secure this essential diagnostic asset for your facility.
Key Attributes
Sample rate: 200 Mhz
Type: Color ScopeMeter
Place of origin: China
Size: 1120 pixels x 765 pixels
Model number: 190-204-III-S
Brand name: Fluke
Customized support: OEM, ODM
Warranty: 1 years
Number of Channels: 4
Bandwidth: 200 Mhz
Rise Time: 1.7 ns
Input Coupling: AC or DC, with ground level indicator
Bandwidth Limiter: 20 MHz and 10 kHz
Resolution: 1120 pixels x 765 pixels
Drip and Dust Proof: IP 51 according to IEC60529
Packaging and Delivery
Selling Units: Single item
Single package size: 52X35X31 cm
Single gross weight: 6.000 kg
